Pratt Burnerd America ATL10-A8 | 10" 3 Jaw Power Chuck A-8 Mount

$3,225.00
Ships:
From Partner Facility
Brand:
Pratt Burnerd America
Chuck Diameter (Inch):
10"
Number of Jaws:
3
Mount:
A-8
Through-Hole Diameter (Decimal Inch):
2.9500"
Through-Hole Diameter (mm):
75mm
Chuck Actuation Style:
Drawbar
Operation Type:
Hydraulic
Ships:
From Partner Facility
IsDiscontinued:
SKU:
50000081
UPC:
Weight:
84.00 LBS
Shipping:
Calculated at Checkout

Product Specifications
Weight 91 lbs
Brand Pratt Burnerd America
Chuck Size 10"
Thru-Hole Diameter (mm) 75mm
Thru-Hole Diameter (Inch) 2.95"
Mount A-8
Maximum Gripping Capacity (Inch) 10.00"
Minimum Gripping Capacity (Inch) 1.220"
Maximum Gripping Force (lb/f) 24,953 lb/f
Maximum Draw Bar Pull (lb/f) 9,667 lb/f
Jaw Stroke Diameter (Inch) 0.346"
Piston Stroke Length (inch) 0.748"
Maximum RPM 4200 RPM
