Sets & Accessories • COUNTERSINKS
237

14 Piece High Speed Steel 3-in-1 82° Cham-Bits
Combined tap/Drill/Countersink Convert Standard Twist Drills Into A
& Bit Sets Combination 82° Drill & Countersink
With 1/4" Quick Change Shank • BeNeFITS:
• Radial relieved cutting edge provides clean
Inch Set • Metric Set • Fully adjustable, can be located anywhere up
chatter free cutting.
Save time - drill, tap & & down the flutes of the drill & locked into shown in use
deburr in one operation position with two driving set screws provided. (drill not included)
BeNeFITS: APPLICATIONS:
• Taper design helps prevent thread damage from • Ideal for machining countersinks for flat
over-drilling. head machine screws.
INCLudeS: Drill DeCiMal BoDy overall orDer PriCe
#
eaCH
Dia.
Size
Dia.
Inch Set 1/8" .1250" 3/8" leNgtH 07-029-800 $32.63
7/8"
• (1) Each of combined drill & tap sizes: 6/32", #30 .1285" 3/8" 7/8" 07-029-803 32.63
8/32", 10/24", 10/32", 12/24", 1/4"-20 #29 .1360" 3/8" 7/8" 07-029-806 32.63
• (1) High torque tested quick change adapter. #21 .1590" 3/8" 7/8" 07-029-809 32.63 Fully
• (1) Each of quick change CRV bit sizes: SL03, #16 .1770" 1/2" 1" 07-029-812 35.09 adjustable
SLOT4, PH1, PH2, PZ1, PZ2 3/16" .1875" 1/2" 1" 07-029-815 35.09
• (1) Carrying case. #7 .2010" 1/2" 1" 07-029-818 35.09
Metric Set 7/32"" .2188" 5/8" 1-1/8" 07-029-821 38.61
• (6) Each combination drill & tap sizes: M3 x 0.5, 1/4" .2500" 5/8" 1-1/8" 07-029-824 38.61
M4 x 0.7, M5 x 0.8, M6 x 1.00, M8 x 1.25, M10 x 1.50 F .2570" 5/8" 1-1/8" 07-029-827 38.61
• (1) High torque tested quick change adapter. 17/64"" .2656" 5/8" 1-1/8" 07-029-830 38.61
• (1) Each of quick change CRV bit sizes: SLOT4, 9/32"" .2810" 5/8" 1-1/8" 07-029-833 38.61
SLOT5, PH1, PH2, PZ1, PZ2 5/16"" .3125" 13/16" 1-3/8" 07-029-836 44.85
• (1) Carrying case. model #comBtdc P .3230" 13/16" 1-3/8" 07-029-839 44.85
3/8"" .3750" 13/16" 1-3/8" 07-029-842 44.85
MoDel orDer PriCe 27/64"" .4210" 1" 1-1/2" 07-029-845 53.38
DeSCriPtioN
# # Per Set 7/16"" .4375" 1" 1-1/2' 07-029-848 53.38
Inch Set COMBTDC 30-513-500 $43.99 1/2"" .5000" 1-1/8" 1-5/8" 07-029-851 69.11
Metric Set COMBTDCMM 30-513-501 54.27 33/64"" .5156" 1-1/8" 1-5/8" 07-029-854 69.11
90° Cham-Bits Drill, chamfer & deburr
in one operation!
SPeCiFiCatioNS: FeATureS:
Drill Size raNge a B C D • Drill length positioning can be
1/8" - #15 7/16" 1/4" 5/8" 5/16" varied instantly.
#14 - #1 1/2 1/4 3/4 3/8 • Patent locking device prevents
A - N 5/8 1/4 1 1/2 any axial movement of Cham-Bit. shown in use
5/16" - 7/16" 3/4 5/16 1-1/4 5/8 • Single point cutter ensures (drill not included)
29/64 - 19/32 15/16 5/16 1-1/2 13/16
5/8 - 11/16 1-1/8 3/8 1-5/8 1 concentricity.
3/4 - 13/16 1-5/16 7/16 1-3/4 1-3/16 Metric & Special Sizes
7/8 - 1 1-7/16 1/2 2 1-5/16 Available, Please Call
DeCiMal orDer PriCe DeCiMal orDer PriCe DeCiMal orDer PriCe DeCiMal orDer PriCe
Size Size Size Size
DiaMeter # eaCH DiaMeter # eaCH DiaMeter # eaCH DiaMeter # eaCH
1/8" .1250" 07-029-500 $27.79 3/16" .1875" 07-029-544 $29.69 17/64" .2656" 07-029-590 $32.02 7/16" .4375" 07-029-650 $35.34
#30 .1285 07-029-502 27.79 #11 .1910 07-029-548 29.69 I .2720 07-029-594 32.02 29/64" .4531 07-029-652 41.21
#29 .1360 07-029-504 27.79 #7 .2010 07-029-556 29.69 9/32" .2812 07-029-600 32.02 15/32" .4688 07-029-656 41.21
9/64" .1406 07-029-508 27.79 13/64" .2031 07-029-558 29.69 5/16" .3125 07-029-610 35.34 1/2" .5000 07-029-660 41.21
#25 .1495 07-029-514 27.79 #3 .2130 07-029-566 29.69 P .3230 07-029-614 35.34 33/64" .5156 07-029-662 41.21
5/32" .1562 07-029-520 27.79 7/32" .2188 07-029-568 29.69 21/64" .3281 07-029-616 35.34 17/32" .5312 07-029-664 41.21
#21 .1590 07-029-524 27.79 B .2380 07-029-578 32.02 11/32" .3438 07-029-622 35.34 5/8" .6250 07-029-674 49.26
#19 .1660 07-029-528 27.79 1/4" .2500 07-029-584 32.02 3/8" .3750 07-029-632 35.34 21/32" .6562 07-029-678 49.26
11/64" .1719 07-029-532 27.79 F .2570 07-029-586 32.02 13/32" .4062 07-029-644 35.34 11/16" .6875 07-029-682 49.26
#17 .1730 07-029-534 27.79 G .2610 07-029-588 32.02 27/64" .4219 07-029-648 35.34 7/8" .8750 07-029-706 71.58
Micro Stop Fixtures & Steel Non-Marking Pad Countersinks
Page 236
Note:
• TTC USA cannot be used with 07-055-455 steel non-marking pads.

model #2 model #80000006

tHreaDeD MoDel orDer PriCe MoDel orDer PriCe APPLICATIONS: FeATureS:
SHaNk # # eaCH # # eaCH Micro Stop Fixtures • 120° seating angle ensures
MiCro StoP FixtureS • For hand tool or machine tool applications. precise axial alignment of
1/4"-28 SC-1 07-052-450 $84.78 2 07-055-450 $165.60 • Accommodates complete selection of Micro threaded shank tools.
3/8"-24 SC-3 07-052-451† 162.63 9 07-055-451* 219.34 Stop countersinks and burring cutters. • Depth of cut control in
7/16"-20 SC-4 07-052-452 191.50 — — — Steel Non-Marking Pad .001" increments.
Steel NoN-MarkiNg PaD • Protect workpiece surface finishes. • #2 fixture & model #80000006
— — — — 80000006 07-055-455 $23.06 • Ensure perpendicular alignment with workpiece. steel marking pad supplied
†7/8" Diameter capacity. *Limited supply. with internal threads.
