QUICK CHANGE PARTING & INSERT BLADE HOLDERS

CUT-OFF & GROOVING HOLDERS

AXA SERIES

#7 UNIVERSAL PARTING BLADE HOLDER ORDER # AXA-7
#7 and #7R Holders are only for use with the PRICE EA. $101.60
Aloris Wedge Grip Carbide Insert blades, T- A B C D BLADE HEIGHT
type blades or with bevel (wedge-shape)
13 1 3 1 1
blades having parallel top and bottom edges, / 16 / 2 / 16 1/ 2 / 2
as shown below. For bevel (see drawing) as ALORIS WEDGE GRIP CARBIDE
well as T-type blades. Enables you to cut- INSERT BLADES ORDER # SGIH 19-3C-A7
off close to chuck. Absence of vibration PRICE EA. $101.68
prevents breaking blades.
PARTING BLADES ORDER # P-2*
PRICE EA. $22.25
3 1
WIDTH “A”: / 32 HEIGHT “B”: / 2
WEDGE AND LOCK SCREW ORDER # WSA-1*
ASSEMBLY FOR HOLDERS #7 PRICE EA. $29.50
HEIGHT ADJUSTMENT ASSEMBLY ORDER # AXA-HA*
PRICE EA. $12.60
#7R UNIVERSAL PARTING BLADE TOOL ORDER # AXA-7R
PRICE EA. $117.00
HOLDER – REVERSIBLE
Has the same features as #7 with the A B C D BLADE HEIGHT
advantage of rear cut-off use.
11 1 3 1 1
/ 16 / 2 / 16 1/ 2 / 2
ALORIS WEDGE GRIP CARBIDE
INSERT BLADES ORDER # SGIH 19-3C-A7
PRICE EA. $101.68
PARTING BLADES ORDER # P-2*
PRICE EA. $22.25
3 1
WIDTH “A”: / 32 HEIGHT “B”: / 2
WEDGE AND LOCK SCREW ORDER # WSA-1*
ASSEMBLY FOR HOLDERS #7 PRICE EA. $29.50
HEIGHT ADJUSTMENT ASSEMBLY ORDER # AXA-HA*
PRICE EA. $12.60

#71 CUT-OFF AND GROOVING HOLDER ORDER # AXA-71
Designed for extremely high rigidity under PRICE EA. $207.00
heavy duty conditions, and cool chatter- A B USED WITH BLADE WIDTHS
free operation at higher speeds. Two 15 13 1 3 1
different blades can be used with this / 16 1 / 16 / 8, / 16 or / 4
holder: wedge grip throwaway insert blade, REVERSIBLE BLADES WITH ORDER NUMBER 71-125-1* 71-187-1* 71-250-1*
or reversible blade with brazed-in carbide BRAZED-IN CARBIDE TIPS
tips. The chip-breaker is an integral part of WIDTH x HEIGHT .120 x 1.50 .187 x 1.50 .250 x 1.50
the blade and cannot be lifted by broken
chips. Simplicity is but one of the major PRICE $71.50 $81.00 $85.50
advantages of the Series 71. Adjustment
of the blade position is simple, the locking WEDGE GRIP THROWAWAY ORDER NUMBER 71-125-1BSL* 71-187-1BSL* 71-250-1BSL*
is accomplished by one screw instead of INSERT BLADES WIDTH x HEIGHT
the usual number of adjusting and .120 x 1.50 .187 x 1.50 .250 x 1.50
clamping screws. The versatility of this tool PRICE $75.00 $83.00 $91.00
is further increased by the availability of a
wide range of cutting edge widths. Holder EXTRACTOR ORDER # ESG-1*
supplied less blade. When ordering brazed (For self-locking carbide insert removal) PRICE EA. $4.40
carbide blades, specify grade A2 or A6.
For carbide cut-off inserts see page 54. WEDGE AND LOCK SCREW ORDER # WSA-6*
ASSEMBLY FOR HOLDERS #7 PRICE EA. $49.50
HEIGHT ADJUSTMENT ASSEMBLY ORDER # AXA-HA*
PRICE EA. $12.60
