Technical information
F478
Materials

Material main
group Material sub-group Quality StNr DIN AFNOR UNI BS JIS SS GOST UNS USA
6 6.1 6.1.4 0.9620 G-X 260 NiCr 4 2 Grade 2 A 0512-00 A 532 I B
Cast iron Cast iron with high alloyed NiCr-LC
lamellar graphite A 532 I A
0.9625 G-X 330 NiCr 4 2 Grade 2 B 0513-00
NiCr-HC
A 532 I D
0.9630 G-X 300 CrNiSi 9 5 2 Grade 2 C; D; E 0457-00
Ni-HiCr
A 532 II C 15%
0.9635 G-X 330 CrMo 15 3 Grade 3 A; B
CrMo-
G-X 300 CrMoNi
0.9640 Grade 3 A; B
15 2
G-X 260 CrMoNi A 532 II D 20%
0.9645 Grade 3 C
20 2 CrMo-
A 532 III A
0.9650 G-X 260 Cr 27 Grade 3 D 0466-00
25% Cr
A 532 III A
0.9655 G-X 300 CrMo 27 1 Grade 3 E
25% Cr
6.2 6.2.1 0.7033 GGG-35.3
Spheroidal cast non alloyed up
iron to 180 HB
0.7040 GGG-40 FGS 400-12 GS 400-12 SNG 420/12 FCD 40 0717-02 VC 42-12 60-40-18
0.7043 GGG-40.3 FGS 370-17 GSO 42/17 SNG 370/17 0717-15 VC 42-12
6.2.2 0.7050 GGG-50 FGS 500-7 GS 500/7 SNG 500/7 FCD 50 0727-02 VC 50-2 65-45-12
non alloyed
above 180 HB
0.7060 GGG-60 FGS 600-3 GS 600/3 SNG 600/3 FCD 60 0732-03 VC 60-2 80-55-06
0.7070 GGG-70 FGS 700-2 GS 700-2 SNG 700/2 FCD 70 0737-01 VC 70-2 100-70-03
0.7080 GGG-80 FGS 800-2 GS 800-2 SNG 800/2 VC 80-2 120-90-02
6.2.3 0.7652 GGG-NiMn 13 7 S-NM 13 7 S-NiMn 13 7
alloyed
0.7660 GGG-NiCr 20 2 S-NC 20 2 S-NiCr 20 2 A 439 Type D-2
A 439
0.7661 GGG-NiCr 20 3 S-NC 20 3 S-NiCr 20 3
Type D-2B
0.7665 GGG-NiSiCr 20 5 2 S-NSC 20 5 2 S-NiSiCr 20 5 2
A 439
0.7670 GGG-Ni 22 S-N 22 S-Ni 22
Type D-2C
A 439
0.7673 GGG-NiMn 23 4 S-NM 23 4 S-NiMn 23 4
Type D-2M
0.7676 GGG-NiCr 30 3 S-NC 30 3 S-NiCr 30 3 A 439 Type D-3
A 439 Type
0.7677 GGG-NiCr 30 1 S-NC 30 1 S-NiCr 30 1
D-3A
0.7680 GGG-NiSiCr 30 5 5 S-NSC 30 5 5 S-NiSiCr 30 5 5 A 439 Type D-4
0.7683 GGG-Ni 35 S-N 35 S-Ni 35 A 439 Type D-5
A 439 Type
0.7685 GGG-NiCr 35 3 S-NC 35 3 S-NiCr 35 3
D-5B
6.3 6.3.1 0.8035 GTW-35-04
GTW (white malle- up to 180 HB
able cast iron)
0.8040 GTW-40-05
0.8045 GTW-45-07
6.3.2
above 180 HB 0.8055 GTW-55
0.8065 GTW-65
6.4 6.4.1
GTS (black malle- up to 180 HB 0.8135 GTS-35-10 MN 35-10 B 340/12
able cast iron)
6.4.2 0.8145 GTS-45-06 P 440/7
above 180 HB
0.8155 GTS-55-04 MP 50-5 P 510/4
0.8165 GTS-65-02 MP 60-3 P 570/3
0.8170 GTS-70-02 IP 70-2 P 690/2
7 7.1 7.1.1 3.0205 Al99
Non-ferrous metal Aluminium non alloyed
3.0255 Al99.5 1050 A
3.0275 Al99.7
Solid carbide tools / Technical information
3.0285 Al99.8
3.0305 Al99.9
7.1.2 3.0505 AlMn0.5Mg0.5
aluminium
wrought alloys, 3.0515 AlMn1
non hardened
3.0517 AlMnCu
3.0525 AlMn1Mg0.5 3005
3.0526 AlMn1Mg1
3.0915 AlFeSi
3.3307 Al99.85Mg0.5
3.3308 Al99.5Mg0.5
3.3315 AlMg1 5005
3.3316 AlMg1.5
3.3317 Al99.85Mg1
