P. 811
HSK-T clamping blocks
C206
f
d A h 2
l 1
L N R
h 2 Type, d A h 1 l 1
[mm] description [mm] [mm] [mm]
32 HSK-T63-KHR00-32 R 63 32 150 XLC.. 32.. E01
32 HSK-T100-KHR00-32 R 100 32 160 XLC.. 32.. E01
32 HSK-T63-KHL00-32 L 63 32 150 XLC.. 32.. E01
32 HSK-T100-KHL00-32 L 100 32 160 XLC.. 32.. E01
Parting and grooving / Tools
E01 11848510 11776816 11776756
GX SX LX FX
C269 C198 C199 C202 C203
