Spotting • DRILLS
23
Solid Carbide Chamfer & Spot Drills
Double Ended
Dual purpose tool
reduces tooling cost
60° IncLuDeD angLe
LENGTH OF
60° inCluDeD angle 90° inCluDeD angle CUT “A”
118 ˚ INCLUDED
# oF
POINT
Size overall FluTeS CuT CuT orDer priCe CuT CuT orDer priCe DRILL DIAMETER ANGLE DRILL
“a”
“B”
“a”
lengTh
“B”
#
eaCh
#
eaCh
OF
1/8" 1-1/2" 2 .105" .105" 20-726-120 $17.59 .085" .062" 20-729-120 $17.59 LENGTH POINT
CUT
“B”
3/16 2 2 .160 .160 20-726-180 23.77 .130 .093 20-729-180 23.77 OVERALL LENGTH
1/4 2-1/2 2 .200 .200 20-726-250 31.17 .140 .110 20-729-250 31.17
1/4 2-1/2 4 .200 .305 20-745-250 31.17 — — — —
3/8 2-1/2 2 .315 .305 20-726-370 48.77 .220 .165 20-729-370 48.77 Features:
3/8 2-1/2 4 — — — — .220 .165 20-749-370 48.77 • Maximizes productivity.
1/2 3 2 — — — — .300 .230 20-729-500 72.55 • Standard 118° point.
1/2 3 4 — — — — .300 .230 20-749-500 72.55 • Chamfering angles have constant form relief for
3/4 4 4 — — — — .470 .350 20-749-750 157.43 more resharpening & a stronger, longer tool life.
Solid Carbide Spade Tools
1/8" Shank • 1-1/2" Overall Length
Strength priority for
chamfering & spot drilling
SpaDe MoDel orDer priCe aPPLICatIONs:
angle # # eaCh • Chamfering.
30° SPD1250-030 20-055-005 $13.32 • Spot drilling in hard materials.
45° SPD1250-045 20-055-006 13.32
60° SPD1250-060 20-055-007 13.32 Features: ToleranCeS:
90° SPD1250-090 20-055-008 13.32 • Submicron grade carbide. Overall Length: ±0.004"
118° SPD1250-118 20-055-009 13.32 Spade Angle: ±1°
Solid Carbide 90° Micro Spot Drills
1/8" Shank • 1-1/2" Overall
Produces mirror
surface finishes
aPPLICatIONs: Features:
• Excels on plastic, copper alloy, aluminum, titanium, nickel alloy, • 4 facet point geometry.
cast iron, stainless, steel and hi-carbon steel. • Sub micron grain carbide.
• Single end construction.
Other Sizs & 130° Included
Angle Available, Please Call
FluTe orDer priCe
Size
lengTh # eaCh
.0312" .090" 20-517-410 $14.26
.0625" .200" 20-517-411 13.92
.0938" .200" 20-517-412 13.75 FOR MIcRO ToleranCeS:
.1250" .200" 20-517-413 13.75 MacHInIng Cutting Diameter: +0 / -0.0003"
aPPLIcaTIOnS
