Rolls & Sheets • SHIM STOCK
1463

Stainless Steel Shim Stock
Inch & Metric APPLICATIONS: FeATureS:
• Used for shimming where corrosive • Full hard, cold rolled, 300 series stainless
environments are an issue. Precision Brand ®
• The only manufacturer to offer
Branded Shim - everything you
®

need to know is right on the shim,
such as material type, thickness,

size, and tracking number.
INch SIzeS 6" x 50" RollS 6" x 50" RollS
ThIckNeSS Model oRdeR PRIce Model oRdeR PRIce
#
#
eAch
#
#
eAch
.001" 10001 71-230-010 $30.69 L-1 71-216-010 $41.49
.002 10002 71-230-020 19.39 L-2 71-216-020 26.39
.003 10003 71-230-030 18.99 L-3 71-216-030 25.19 MeTRIc SIzeS 150mm x 1.25m 150mm x 1.25m
.004 10004 71-230-040 20.29 L-4 71-216-040 24.59 ThIckNeSS Model oRdeR PRIce Model oRdeR PRIce
.005 10005 71-230-050 22.49 L-5 71-216-050 28.29 # # eAch # # eAch
.006 10006 71-230-060 22.49 — — — .05mm 13005 71-230-500 $18.79 MMSS05 71-216-500 $27.69
.007 10007 71-230-070 22.49 — — — .10 13010 71-230-505 19.39 MMSS10 71-216-505 28.39
.008 10008 71-230-080 23.69 L-8 71-216-080 29.69 .15 13015 71-230-510 20.69 MMSS15 71-216-510 29.69
.010 10010 71-230-100 23.69 L-10 71-216-100 30.69 .20 13020 71-230-515 21.79 MMSS20 71-216-515 31.29
.012 10012 71-230-120 23.69 L-12 71-216-120 32.19 .25 13025 71-230-520 21.69 MMSS25 71-216-520 32.29
.015 10015 71-230-150 26.89 L-15 71-216-150 34.69 .30 13030 71-230-525 23.09 MMSS30 71-216-525 33.89
.020 10020 71-230-200 30.99 L-20 71-216-200 41.19 .40 13040 71-230-530 25.09 MMSS40 71-216-530 36.89
.025 10025 71-230-250 35.79 L-25 71-216-250 48.29 .50 13050 71-230-535 29.49 MMSS50 71-216-535 43.59
.031 10031 71-230-310 40.79 L-31 71-216-310 54.99 .80 13080 71-230-545 40.69 MMSS80 71-216-545 57.89
Blue Tempered Spring Steel Shim Stock
APPLICATIONS:

• Offers toughness and fatigue resistance
for high wear applications.

Model oRdeR PRIce Model oRdeR PRIce
SIze FeATureS:
# # eAch # # eAch
RollS (50" leNgTh) • High carbon 1095 hardened and
tempered spring steel.
3" x .002" 60002 71-250-020 $27.39 C-2 71-223-020 $35.19 Precision Brand ®
3 x .003 60003 71-250-030 28.59 C-3 71-223-030 37.09 • The only manufacturer to offer
5 x .004 60004 71-250-040 31.89 C-4 71-225-040 35.69 ®
6 x .005 60005 71-250-050 27.39 C-5 71-226-050 31.49 Branded Shim - everything you
6 x .006 60006 71-250-060 27.39 — — — need to know is right on the shim,
6 x .007 60007 71-250-070 29.39 C-7 71-226-070 36.79 such as material type, thickness, size
FlAT SheeTS (6" x 25") and tracking number.
.008" 60908 71-240-080 $31.89 CY-8 71-228-080 $37.39
.010 60910 71-240-100 33.89 CY-10 71-228-100 40.39
.012 60912 71-240-120 35.99 CY-12 71-228-120 41.99
.015 60915 71-240-150 37.99 CY-15 71-228-150 52.09 NoTe:
.020 60920 71-240-200 43.99 CY-20 71-228-200 53.09
.025 60925 71-240-250 49.49 CY-25 71-228-250 68.09 • Flat sheets are packaged 2 sheets
.032 60932 71-240-320 55.69 CY-32 71-228-320 67.19 per package.
Flat Shim Assortments Flat Shim Assortments
6" x 12" Flat Sheets • 6" x 12" Flat Sheets • Steel Or Brass
Blue Tempered Or Stainless Steel Multi-purpose
usages
APPLICATIONS: APPLICATIONS:
• Used in production & maintenance • Used in production and maintenance
areas where a variety of thicknesses areas where a variety of thicknesses
are needed. are needed.
INCLudeS: INCLudeS:
6 Piece Blue Tempered Sheet Set 12 Sheet Set
• (1) Each thickness: .005", .010", .015", MODEL • (1) Each thickness: .001", .0015", .002",
#23CR6
.020", .025", .032" .003", .004", .005", .006", .007", .008",
8 Piece Stainless Steel Sheet Set .010", .012", .015"
• (1) Each thickness: .001", .002", .003", 15 Sheet Set
.005", .008", .010", .015", .020" • (1) Each thickness: .001", .0015", .002",
.003", .004", .005", .006", .007", .008", MODEL
.010", .012", .015", .020", .025", .031" #16AF-15
MODEL
#22LF8 deScRIPTIoN Model oRdeR PRIce
# # PeR SeT
Model oRdeR PRIce 12 Piece Steel Assortment 16AF-12 71-202-902 $41.69
deScRIPTIoN
# # PeR SeT 12 Piece Brass Assortment 17SF-12 71-201-902 57.69
6 Piece Blue Tempered Sheet Set 23CR6 71-223-901 $65.69 15 Piece Steel Assortment 16AF-15 71-202-901 50.19
8 Piece Stainless Steel Sheet Set 22LF8 71-216-901 97.09 15 Piece Brass Assortment 17SF-15 71-201-901 78.59
