Combination Tools & Contour Cutters • COUNTERSINKS
239

Cobalt Self-Centering Combined Tap Drill & Countersink Tools
For Flat-Head Cap Screws • Cylindrically Ground • Bright Finish

APPLICATIONS: FeATureS:
• Produce holes properly sized for each size screw. • Right hand (clockwise
• Dual cutting diameters permit both the tap rotation) cutting direction.
drill hole and countersink to be machined in • Standard two flute design.
one operation. • Standard spiral, helical flutes. unique CuTTing
• For NC conventional machining and in both • Straight shanks correspond to end reduCes
aPPliCaTions
manual or automatic drilling machines. normal stub drill diameters.
[C19] L1 - 1/4" L2 - 3/8" L3 - 1/2" L4 - 5/8" L5 - 3/4" L6 - 1"
“B” BaSiC
TaP OrDer PriCe OrDer PriCe OrDer PriCe OrDer PriCe OrDer PriCe OrDer PriCe
SizeS STuB DriLL # eaCh # eaCh # eaCh # eaCh # eaCh # eaCh
DiameTer
#4-40 3/16" 07-029-001 $25.75 07-029-002 $25.75 — — — — — — — —
4-48 3/16 — — — — 07-029-008* $21.80 — — — — — —
5-40 3/16 — — 07-029-012* 21.80 — — — — — — — —
5-44 3/16 07-029-016* 21.80 07-029-017* 21.80 07-029-018* 21.80 — — — — — —
6-32 3/16 07-029-021 28.33 07-029-022 25.75 — — — — — — — —
6-40 3/16 — — 07-029-027* 21.80 07-029-028* 21.80 — — — — — —
8-32 3/16 07-029-031 28.33 — — 07-029-033 28.33 — — — — — —
8-36 3/16 — — — — 07-029-038* 21.80 — — — — — —
10-24 1/4 — — 07-029-042 28.78 07-029-043 28.78 — — — — — —
10-32 1/4 07-029-051 26.17 07-029-052 26.17 07-029-053 26.17 — — — — — —
12-24 5/16 — — — — — — — — 07-029-065* $22.78 07-029-066* $22.78
12-28 5/16 07-029-071 26.96 — — 07-029-073* 22.78 07-029-074* $6.04 07-029-075* 22.78 — —
1/4"-20 5/16 07-029-081 29.66 07-029-082 26.96 07-029-083 26.96 07-029-084 26.96 07-029-085 26.96 07-029-086 26.96
5/16-18 3/8 — — 07-029-102 27.76 — — 07-029-104 27.76 — — — —
5/16-24 3/8 07-029-111* 23.48 — — — — — — — — 07-029-116* 23.48
3/8-16 1/2 07-029-121 30.29 — — 07-029-123 30.29 — — — — 07-029-126 30.29
3/8-24 1/2 — — — — — — — — — — 07-029-136* 25.83
7/16-14 1/2 — — 07-029-142* 6.80 — — 07-029-144* 25.83 07-029-145* 25.83 07-029-146* 25.83
7/16-20 1/2 — — 07-029-152* 25.83 07-029-153* 25.83 07-029-154* 25.83 — — 07-029-156* 25.83
1/2-13** 5/8 — — — — 07-029-163 33.88 07-029-164* 26.58 07-029-165* 26.58 07-029-166 33.88
1/2-20** 5/8 — — 07-029-172* 26.58 07-029-173* 26.58 07-029-174* 26.58 — — — —
*Limited Supply. **Made of high speed steel.
Carbide Tipped Coolant Fed Port Contour Cutters
SAE J1926/MS16142 & SAE AS5202/MS33649
Carbide tipped for exceptional tool
life & use on tough materials

APPLICATIONS: FeATureS:
• Machine fluid control. • Reamer style pilots.
• SAE & MS standard port contour cutters. • Tolerance meets SAE & MS requirements. Model #CTPC-312-24
• For drilled or cast holes. • Coolant holes aim coolant directly on cutting area.
• Port contour cutters are used to produce a proper • 3 effective flutes minimizes harmonics.
fit on high pressure hydraulic fittings. • Center ground within .0002" concentricity.
Sae J1926/mS16142
______________________________________DimenSiOnS______________________________________
POrT Pre DriLL TuBe mODeL OrDer PriCe
Size Size # ____a____ __B__ ___C___ __D__ ____e____ _F_ __g__ __h__ __J__ # # eaCh
+.00" / -.01" ±.002" min. Dia. ±.008" min. LengTh ±1° -.0005" LengTh LengTh
5/16"-24 0.25" 2 0.272" 0.36" 0.669" 0.083" 0.472" 12° 1/2" 1-1/2" 2" CTPC-312-24 24-120-300 $171.98
3/8-24 0.31 3 0.335 0.423 0.748 0.083 0.472 12° 1/2 1-1/2 2 CTPC-375-24 24-120-301 171.98
7/16-20 0.37 4 0.389 0.49 0.827 0.102 0.551 12° 1/2 1-1/2 2 CTPC-438-20 24-120-302 171.98
1/2-20 0.44 5 0.452 0.553 0.906 0.102 0.551 12° 1/2 1-1/2 2 CTPC-500-20 24-120-303 177.04
9/16-18 0.48 6 0.509 0.618 0.984 0.106 0.61 12° 1/2 1-1/2 2 CTPC-562-18 24-120-304 177.04
3/4-16 0.67 8 0.689 0.813 1.181 0.106 0.689 15° 3/4 1-1/2 2 CTPC-750-16 24-120-305 194.24
7/8-14 0.78 10 0.806 0.945 1.339 0.106 0.787 15° 3/4 2 2 CTPC-875-14 24-120-306 217.51
1-1/16-12 0.95 12 0.981 1.15 1.614 0.138 0.906 15° 3/4 2 2 CTPC-1.062-12 24-120-307 234.32
1-3/16-12 1.09 14 1.106 1.276 1.772 0.138 0.906 15° 3/4 2 2 CTPC-1.188-12 24-120-308 242.80
1-5/16-12 1.21 16 1.231 1.4 1.929 0.138 0.906 15° 3/4 2 2 CTPC-1.312-12 24-120-309 257.98
1-5/8-12 1.53 20 1.544 1.715 2.283 0.138 0.906 15° 1 2 2 CTPC-1.625-12 24-120-310 288.33
1-7/8-12 1.78 24 1.794 1.965 2.559 0.138 0.906 15° 1 2 2 CTPC-1.875-12 24-120-311 360.16
Sae aS5202/mS33649
Pre ________________________________________DimenSiOnS________________________________________
POrT Size TuBe mODeL OrDer PriCe
(unJF & unJ) DriLL # __a__ ____B____ ____C____ __D__ ___e___ _____F_____ _____g_____ __h__ __J__ # # eaCh
Size ±.002" +.005"/-.000" +.015"/-.000" min. Dia. min. LengTh +.015"/-.000" -.0005"/-.0010" LengTh LengTh
3/8"-24 0.31" 3 .390" .390" .500" .688" .588" .063" 1/2" 1-1/2" 2" CTPC-375-24-649 24-120-350 $185.21
1/2"-20 0.43" 5 .517" .517" .625" .812" .661" .075" 1/2" 1-1/2" 2" CTPC-500-20-649 24-120-352 190.66
9/16"-18 0.49" 6 .580" .580" .688" .875" .714" 0.083" 1/2" 1-1/2" 2" CTPC-562-18-649 24-120-353 177.04
5/8"-18 0.55" 7 .643" .643" .750" .938" .730" .094" 1/2" 1-1/2" 2" CTPC-625-18-649 24-120-354 194.24
1-5/16"-12 1.21" 16 1.336" 1.336" 1.487" 1.688" 1.069" .125" 3/4" 2" 2" CTPC-1.312-12-649 24-120-359 257.98
