Interchangeable Pilot Type • COUNTERBORES
243

40 Piece Counterbore Set
High Speed Steel • Straight Shank

APPLICATIONS: INCLudeS:
• Used to enlarge the opening of a hole to • Supplied in fitted case.
allow room for the head of a screw. 26 Pilots
FeATureS: • 3/32" shank: 1/8", 5/32", 3/16", 1/4"
• Complete set allow you to be organized. • 5/32" shank: 3/16", 7/32", 1/4", 9/32", 5/16"
• Wide selection of counterbore sizes & pilots. • 3/16" shank: 1/4", 5/16", 3/8", 7/16", 1/2"
• 1/4" shank: 5/16", 3/8", 7/16", 1/2", 9/16", 5/8"
• 5/16" shank: 3/8", 7/16", 1/2", 9/16", 5/8", 3/4"
model order PrICe 13 Counterbores
# # Per SeT • 1/4" thru 1" by 16ths.
C1-40S 07-011-100 $469.99
Carbide Tipped Counterbores
Interchangeable Pilot Types • Straight Shank & Taper Shank

APPLICATIONS:
• Used to enlarge the opening of a hole to
allow room for the head of a screw. STRAIGHT SHANK TAPER SHANK
• For non-ferrous materials.
STraIghT Shank [C11] TaPer Shank [C11T] STraIghT Shank [C11] TaPer Shank [C11T]
hole Shank order PrICe morSe order PrICe hole Shank order PrICe morSe order PrICe
SIze SIze
dIameTer dIameTer # eaCh TaPer # eaCh dIameTer dIameTer # eaCh TaPer # eaCh
1/4" 3/32" 15/64" 24-120-016 $66.81 1 24-121-016 $78.14 1" 5/16" 1" 24-120-064 $114.61 3 24-121-064 $130.97
5/16 3/32 19/64 24-120-020 74.20 1 24-121-020 85.47 1-1/16 5/16 1 24-120-068 115.83 3 24-121-068 132.67
3/8 5/32 5/16 24-120-024 78.62 1 24-121-024 88.20 1-1/8 5/16 1 24-120-072 118.79 3 24-121-072 136.85
7/16 5/32 3/8 24-120-028 80.69 1 24-121-028 90.63 1-3/16 5/16 1 24-120-076 124.06 3 24-121-076 141.51
1/2 3/16 7/16 24-120-032 89.60 1 24-121-032 100.01 1-1/4 3/8 1 24-120-080 138.18 3 24-121-080 157.32
9/16 3/16 1/2 24-120-036 92.20 1 24-121-036 101.89 1-5/16 3/8 1 24-120-084 149.14 3 24-121-084 168.65
5/8 3/16 1/2 24-120-040 93.10 2 24-121-040 104.61 1-3/8 3/8 1-1/4 24-120-088 156.89 3 24-121-088 176.70
11/16 3/16 1/2 24-120-044 98.62 2 24-121-044 110.38 1-7/16 3/8 1-1/4 24-120-092 171.98 4 24-121-092 196.57
3/4 1/4 1/2 24-120-048 100.86 2 24-121-048 112.25 1-1/2 3/8 1-1/4 24-120-096 191.60 4 24-121-096 217.96
13/16 1/4 5/8 24-120-052 102.98 2 24-121-052 114.25 1-9/16 7/16 1-1/4 24-120-100 197.18 4 24-121-100 234.17
7/8 1/4 3/4 24-120-056 109.16 2 24-121-056 120.07 1-5/8 7/16 1-1/4 24-120-104 201.36 4 24-121-104 238.36
15/16 1/4 3/4 24-120-060 111.41 3 24-121-060 123.33
Interchangeable Pilots

APPLICATIONS:
• For straight shank and taper shank (short series) counterbores.
• Interchangeable with different counterbores to produce various combinations of sizes.
7/16" SHANK
[C3] [C3] [C3] [C3] [C3]
PIloT order PrICe PIloT order PrICe PIloT order PrICe PIloT order PrICe PIloT order PrICe
SIze # eaCh SIze # eaCh SIze # eaCh SIze # eaCh SIze # eaCh
3/32" Shank 3/16" Shank 5/16" Shank 3/8" Shank (ConT’d) 1/2" Shank
1/8" 07-010-008 $4.06 7/32" 07-012-014 $4.68 3/8" 07-014-024 $5.00 1-5/16" 07-015-084 $20.76 9/16" 07-017-036 $8.39
5/32 07-010-010 4.06 1/4 07-012-016 4.68 7/16 07-014-028 5.62 1-3/8 07-015-088 21.79 5/8 07-017-040 9.22
3/16 07-010-012 4.06 9/32 07-012-018 5.00 1/2 07-014-032 6.44 1-7/16 07-015-092 22.87 11/16 07-017-044 9.43
7/32 07-010-014 4.68 5/16 07-012-020 5.00 9/16 07-014-036 8.39 7/16" Shank 3/4 07-017-048 10.71
1/4 07-010-016 4.68 11/32 07-012-022 5.00 5/8 07-014-040 9.22 1/2" 07-016-032 $6.44 13/16 07-017-052 12.05
9/32 07-010-018 5.00 3/8 07-012-024 5.51 11/16 07-014-044 9.43 9/16 07-016-036 8.39 7/8 07-017-056 13.28
1/8" Shank 13/32 07-012-026 5.51 3/4 07-014-048 10.71 5/8 07-016-040 9.22 15/16 07-017-060 14.01
5/32" 07-009-010 $4.06 7/16 07-012-028 5.62 13/16 07-014-052 11.03 11/16 07-016-044 9.43 1 07-017-064 14.84
3/16 07-009-012 4.17 15/32 07-012-030 5.92 7/8 07-014-056 13.28 3/4 07-016-048 10.71 1-1/16 07-017-068 15.04
7/32 07-009-014 4.68 1/2 07-012-032 6.44 15/16 07-014-060 14.01 13/16 07-016-052 12.05 1-1/8 07-017-072 18.18
1/4 07-009-016 4.68 9/16 07-012-036 8.39 1 07-014-064 15.14 7/8 07-016-056 13.28 1-3/16 07-017-076 18.69
9/32 07-009-018 5.00 5/8 07-012-040 9.22 1-1/16 07-014-068 15.35 15/16 07-016-060 14.01 1-1/4 07-017-080 19.73
5/16 07-009-020 5.00 1/4" Shank 1-1/8 07-014-072 18.18 1 07-016-064 14.84 1-5/16 07-017-084 20.76
11/32 07-009-022 5.00 9/32" 07-013-018 $5.00 3/8" Shank 1-1/16 07-016-068 15.04 1-3/8 07-017-088 21.79
3/8 07-009-024 5.51 5/16 07-013-020 5.00 7/16" 07-015-028 $5.62 1-1/8 07-016-072 18.18 1-7/16 07-017-092 22.87
13/32 07-009-026 5.51 11/32 07-013-022 5.00 1/2 07-015-032 6.44 1-3/16 07-016-076 18.69 1-1/2 07-017-096 23.90
7/16 07-009-028 5.51 3/8 07-013-024 5.51 9/16 07-015-036 8.39 1-1/4 07-016-080 19.73 1-9/16 07-017-100 24.93
15/32 07-009-030 5.92 13/32 07-013-026 5.51 5/8 07-015-040 9.22 1-5/16 07-016-084 20.76 1-5/8 07-017-104 25.44
1/2 07-009-032 6.65 7/16 07-013-028 5.62 11/16 07-015-044 10.00 1-3/8 07-016-088 21.79 1-11/16 07-017-108 28.53
9/16 07-009-036 7.78 15/32 07-013-030 5.92 3/4 07-015-048 10.71 1-7/16 07-016-092 22.87 1-3/4 07-017-112 31.15
5/32" Shank 1/2 07-013-032 6.44 13/16 07-015-052 11.03 1-1/2 07-016-096 23.90 1-13/16 07-017-116 34.25
07-017-120
1-7/8
38.93
3/16" 07-011-012 $4.17 9/16 07-013-036 8.39 7/8 07-015-056 13.28 1-9/16 07-016-100 24.93 1-15/16 07-017-124 40.48
7/32 07-011-014 4.68 5/8 07-013-040 9.22 15/16 07-015-060 14.01 1-5/8 07-016-104 25.44 2 07-017-128 42.59
1/4 07-011-016 4.68 11/16 07-013-044 9.43 1 07-015-064 14.84 1-11/16 07-016-108 28.53
9/32 07-011-018 5.00 3/4 07-013-048 10.71 1-1/16 07-015-068 15.04 1-3/4 07-016-112 31.15
5/16 07-011-020 5.00 13/16 07-013-052 11.03 1-1/8 07-015-072 18.18 1-13/16 07-016-116 34.25
11/32 07-011-022 5.00 7/8 07-013-056 13.28 1-3/16 07-015-076 18.69 1-7/8 07-016-120 38.93
3/8 07-011-024 5.51 1-1/4 07-015-080 19.73
