MICRO 100 / M100DEX • Turning - Holders / Milling - Holder, Inserts & Sets
560

90° Turning & Facing Toolholders
95° Approach • Utilizes ANSI Standard CCMT 21.51 Insert

features:
• Insert has a 4 layered coating (TiN,
Al203, TiCN & TiC) for extended wear
and tool life.
RiGHt HAnd
♦ Insert Not Included.
InSErT
InSErT OrdEr _____PrICE EaCh_____
TurnIng & FaCIng TOOlhOldErS rIghT hand lEFT hand # # 1-9 PCS. 10+ PCS.
SquarE OvErall F OvEr MOdEl OrdEr PrICE OrdEr PrICE CCMT 21.51 24-525-108 $11.39 $10.25
Shank lEngTh InSErT # # EaCh # EaCh
1/4" 2-1/2" .394" SCLCR/L 0404 D2 24-525-072 $38.80 24-525-082 $38.80 rEPlaCEMEnT ParTS
5/16 2-1/2 .394 SCLCR/L 0505 D2 24-525-074 42.08 24-525-084 42.08 dESCrIPTIOn MOdEl OrdEr PrICE
3/8 2-3/4 .472 SCLCR/L 0606 E2 24-525-076 47.28 24-525-086 47.28 # # EaCh
1/2 3 .629 SCLCR/L 0808 F2 24-525-078 51.70 24-525-088 51.70 Torx Screw 16-1020 24-525-116 $3.95
®
5/8 4 .787 SCLCR/L 1010 H2 24-525-080 57.32 24-525-090 57.32 Torx Key 16-1060 24-525-118 3.65
®
Indexable 90° Square Shoulder End Mills
Utilizes ANSI Standard APKT 1003 PDR Inserts
InSErTS
Indexable tool provides great value when compared InSErT OrdEr ___PrICE EaCh___
to solid carbide single point end mills # # 1-9 PCS. 10+ PCS.
APKT 1003 PDR 24-525-112* $7.57 —
APKT 1003 PDR 24-525-120
Benefits: features: *Old Order # For Previous Design. 12.62 $11.36
• Indexable tool provides great value when • Insert has a new coating for extended wear
compared to solid carbide single point and tool life. rEPlaCEMEnT ParTS
end mills. • Insert is not supplied with indexable dESCrIPTIOn MOdEl OrdEr PrICE
end mills. # # EaCh
• New tool design. Torx Screw 16-1020 24-525-116 $3.95
®
Torx Key 16-1060 24-525-118 3.65
®
End MIllS
CuTTEr Shank OvErall CuTTEr # OF InSErTS MOdEl OrdEr PrICE
dIaMETEr dIaMETEr lEngTh l rEquIrEd # # EaCh
3/8" 1/2" 3" 1-1/2" 1 BAAP 1216 2 24-525-046 $110.01
1/2 1/2 3 1-1/2 1 BAAP 1616 2 24-525-048 122.91
5/8 1/2 3 1-1/2 2 BAAP 1816 2 24-525-050 135.87
3/4 3/4 4-3/8 2 3 BAAP 2424 2 24-525-052 187.57
1 3/4 4-3/8 2 4 BAAP 3224 2 24-525-054 200.46
♦ Insert Not Included. 1-1/4 3/4 4-3/8 2 5 BAAP 4024 2 24-525-056 298.72
Indexable Coolant-Thru 90° Square Shoulder End Mills & Set
Utilizes ANSI Standard APKT 1003 PDR Inserts
features: InSErTS
• Insert has a new coating for extended ___PrICE EaCh___
wear and tool life. InSErT OrdEr 1-9 PCS. 10+ PCS.
#
#
• Insert is not supplied with individual APKT 1003 PDR 24-525-112* $7.57 —
end mill purchase. APKT 1003 PDR 24-525-120 12.62 $11.36
• New tool design. *Old Order # For Previous Design.
includes: rEPlaCEMEnT ParTS
3 Piece Set MOdEl OrdEr PrICE
• (1) Carbide insert for each end mill. dESCrIPTIOn # # EaCh
• (1) Torx screw for each end mill. Torx Screw 16-1020 24-525-116 $3.95
®
®
• (1) Torx key. Torx Key 16-1060 24-525-118 3.65
®
®
3 PIECE SET
CuTTEr Shank # OF InSErTS MOdEl OrdEr PrICE
dIaMETEr dIaMETEr rEquIrEd # # PEr SET
3/8" 1/2" 1
3 Piece Set
1/2 1/2 1 60-3003 24-525-058 $316.88
5/8 1/2 2
End MIllS
CuTTEr Shank OvErall CuTTEr # OF InSErTS MOdEl OrdEr PrICE
dIaMETEr dIaMETEr lEngTh l rEquIrEd # # EaCh
end Mill 3/8" 1/2" 3" 1-1/2" 1 AAAP 1216 2 24-525-060 $135.87
♦ Insert Not Included. 1/2 1/2 3 1-1/2 1 AAAP 1616 2 24-525-062 148.71
5/8 1/2 3 1-1/2 2 AAAP 1816 2 24-525-064 162.34
3/4 3/4 4-3/8 2 3 AAAP 2424 2 24-525-066 191.20
1 3/4 4-3/8 2 4 AAAP 3224 2 24-525-068 306.47
1-1/4 3/4 4-3/8 2 5 AAAP 4024 2 24-525-070 328.47
