ALORIS INDEXABLE TOOL POST OPTIONS

“T” NUT BLANK
ORDER # BXA-I-TB* ORDER # CA-I-TB* ORDER # DA-I-TB*
PRICE EA. $52.80 PRICE EA. $81.60 PRICE EA. $102.00
“T” DIM 1 /2" 3 /4" 7 /8"
1
1
T L “B” DIM 2 /4" 2 /2" 3"
1
1
1
B “L” DIM 2 /2" 3 /2" 4 /2"
Nut and stud included. Customer to machine. Furnished with tapped hole only.
OPTIONAL “T” NUT MACHINED
(FILL OUT CHART BELOW) ORDER # BXA-I-TM* ORDER # CA-I-TM* ORDER # DA-I-TM*
PRICE EA. $39.75 PRICE EA. $52.80 PRICE EA. $66.00
Machined by Aloris. Ready for installation.

OPTIONAL ANTI-ROTATION KEY
(CUSTOMER TO FINISH “C” ORDER # BXA-I-ARS* ORDER # CA-I-ARS* ORDER # DA-I-ARS*
DIMENSION IN THE CHART BELOW) PRICE EA. $72.00 PRICE EA. $79.50 PRICE EA. $99.75
Semi-finished.
OPTIONAL “C” DIM. ANTI-ROTATION KEY
(ALORIS TO FINISH “C” ORDER # BXA-I-ARF* ORDER # CA-I-ARF* ORDER # DA-I-ARF*
DIMENSION IN THE CHART BELOW) PRICE EA. $199.00 PRICE EA. $236.50 PRICE EA. $273.00
Finished and assembled by Aloris. (Precision Ground.)

“T” NUT ORDERING INFORMATION (Please Complete Chart and Fax)

MAKE OF LATHE SWING A B C D E

When ordering, please give name and swing of lathe or specified dimensions. Please fax the above chart with your order.
Without this information “T” nut will be supplied blank. There is an extra charge for riser-blocks.
Ball
INDEXABLE TOOL POST
Stud Handle
REPLACEMENT PARTS
Not interchangeable with standard tool post parts.
“T” BOLT ASSY = “T”-NUT AND STUD (INDEXABLE)
ORDER # BXA-I-TB* CA-I-TB* DA-I-TB*
PRICE EA. $52.80 $81.60 $102.00

HANDLES (INDEXABLE)
ORDER # BXA-I-HANDLE* CA-I-HANDLE* DA-I-HANDLE*
PRICE EA. $39.75 $49.20 $55.20
C
BALLS (INDEXABLE)
D ORDER # BXA-I-BALL* CA-I-BALL* DA-I-BALL*
B PRICE EA. $7.20 $8.20 $8.20

FLANGE NUTS (INDEXABLE)
Anti-Rotational ORDER # BXA-I-FN* CA-I-FN* DA-I-FN*
Key
PRICE EA. $13.75 $16.85 $21.60
LOCKING WRENCH
“T”-Nut
ORDER # BXA-I-LW* CA-I-LW* DA-I-LW*
A PRICE EA. $86.40 $86.40 $86.40
SQUARE
