Page 1251 - Ceratizit Catalog

WD828-L, coated
F254
Solid carbide milling cutters for plastics

Ø d A
Ø d 1
SCPX210
l 2
l 1

HA
d 1 Type, d A l 1 l 2
[mm] description [mm] [mm] [mm] Material
4.0 R.V.D828.0400.L.S.HA 4 50 16 WD828040260
5.0 R.V.D828.0500.L.S.HA 5 50 16 WD828050260
6.0 R.V.D828.0600.L.S.HA 6 60 19 WD828060260
8.0 R.V.D828.0800.L.S.HA 8 63 25 WD828080260
10.0 R.V.D828.1000.L.S.HA 10 72 25 WD828100260
12.0 R.V.D828.1200.L.S.HA 12 83 32 WD828120260
16.0 R.V.D828.1600.L.S.HA 16 92 36 WD828160260
20.0 R.V.D828.2000.L.S.HA 20 104 45 WD828200260

Feed rate in mm / revolution.

Solid carbide tools / Milling
