Page 551 - Ceratizit Catalog

MaxiMill 260 system
B224
LP.. (026) / TP.. (025) / SP.. (018)

P ●●●●●●○○○ ○ ○
M ● ○○●●● ●
K ○●●● ●●●● ○●●○ ●
N ●●●●
S ●●
H ○ ●
CTEP210 TCM10 CTCP220 CTPP225 CTCP230 CTPP235 CTPM225 CTCM235 CTPM240 CTN3105 CTL3215 CTCK215 CTPK220 CTD4205 AMZ H216T CTW4615 CTC5235 CTC5240 CTP6215 d l s r d 1

12.70
LPHT 200408ER-29 ● [mm] [mm] [mm] [mm] [mm]
5.50
4.76
0.80
20.00
-29

LPHW 200408ER ● 12.70 20.00 4.76 0.80 5.50
LPHW LPHW 200408SR ● 12.70 20.00 4.76 0.80 5.50

SPKT 1204EDSR-29 ● 12.70 12.70 4.76 0.25 5.50
-29

SPEX 1204EETR ● 12.70 12.00 4.76 5.50
SPEX

SPKW 1204EDER ● 12.70 12.70 4.76 0.25 5.50
SP..W SPKW 1204EDSR ● 12.70 12.70 4.76 0.25 5.50

TPKW 2204PDER ● 12.70 20.80 4.76 1.20 5.50
TPKW TPKW 2204PDSR ● 12.70 20.80 4.76 1.20 5.50

d l s r d 1
CTEP210 TCM10 CTCP220 CTPP225 CTCP230 CTPP235 CTPM225 CTCM235 CTPM240 CTN3105 CTL3215 CTCK215 CTPK220 CTD4205 AMZ H216T CTW4615 CTC5235 CTC5240 CTP6215
r r
d 1
d
d d 1 d l 1 d 1
11° 11° 11°
l s R=400
l s s

Milling / Cassette milling cutters
