MaxiLock D/N
A66
CN..

P ●●●●● ●○○○
M ○●○○○●●● ○○
K ○○●● ○ ●●●
N ○ ●
S ○○○○ ●●
H
CTEP110 TCM10 CTCP115 CTCP125 CTCP135 CTP2120 CTPM125 CTC2135 CTC3110 CTCK120 H10T CTP5110 CTP5115 d l s r d 1

19.30
6.35
CNMM 190616SN-R88 ●●● [mm] [mm] [mm] [mm] [mm]
19.05
7.94
1.60
-R88 CNMM 190624SN-R88 ●●● 19.05 19.30 6.35 2.40 7.94
●●●
9.12
25.80
9.52
25.40
2.40
CNMM 250924SN-R88
CNMT 320932SN-R88 ●●● 31.75 32.24 9.52 3.20 9.12
CNMM 190624SN-R88Q ●● 19.05 19.30 6.35 2.40 7.94
-R88Q

CNMA 120404EN ● 12.70 12.90 4.76 0.40 5.16
CNMA 120408EN ●● 12.70 12.90 4.76 0.80 5.16
CNMA 120412EN ●● 12.70 12.90 4.76 1.20 5.16
CNMA 120416EN ● 12.70 12.90 4.76 1.60 5.16
CN..A CNMA 160608EN ● 15.88 16.10 6.35 0.80 6.35
CNMA 160612EN ● 15.88 16.10 6.35 1.20 6.35
CNMA 160616EN ● 15.88 16.10 6.35 1.60 6.35
CNMA 190612EN ● 19.05 19.30 6.35 1.20 7.94
CNMA 190616EN ● 19.05 19.30 6.35 1.60 7.94
r
s
l
d
CTEP110 TCM10 CTCP115 CTCP125 CTCP135 CTP2120 CTPM125 CTC2135 CTC3110 CTCK120 H10T CTP5110 CTP5115
d 1
d 80° d 1 d 80° d 1
r l s r l s

Turning / Inserts
V
C
A13 A24 A297 □ A109-A111 □ A121-A123 ⌀ A228 ⌀ A232
HSK A181-A183 UTS A201 HSK A255 UTS A261
