CERATIZIT designation system
                                                                                                                   D4
                                                                                                 Drilling tools




                                               C 900. 5D. 260.R. 08




                                                1        2             3            4           5         6

                                                                   3D. 260.R. 05




                                                                       3            4           5         6





         1                                 2                  3                  4

         Connection/interface              System              Length             Drilling diameter

         C      = round shank              MaxiDrill 900       2D                 260 = 26,0 mm
                                                               3D
         UT40   = UTS adapter
                                                               4D
                                                               5D






















         5                           6
                           R                H
         Direction of rotation        Insert size

         R = right-hand
                        L          O          S




                               A C D V        Z Z
                      T


                                   X
                      W
