CERATIZIT designation system
D6
Inserts
4 5 6
Form of top Insert size Insert thickness
surface
A Type Index [mm]
W 02 3,39
F 03 3,97
05 5,29
G 06 6,62
07 7,94 Index s [mm]
03 4,30 02 2,3
M
04 4,20 02 2,5
05 4,80 03 3,0
N
S 06 5,50 T3 3,8
07 6,10 18 1,8
Q d d
08 7,30 21 2,1
L L
09 8,90 23 2,3
R 25 2,5
10 9,60
12 11,60 29 2,9
T 13 12,20 33 3,3
15 14,40 38 3,8
U 17 16,70 44 4,4
48 4,8
W 50 5,0
53 5,3
X Special shapes
56 5,6
10
Chip groove
Chip groove designation
F.. = Fine machining
M.. = Medium machining
R.. = Rough machining
Additional characteristics:
R = Blend radius main/secondary
cutting edge
Q = Masterfinish
Drilling / Introduction
