Page 37 - Parlec Catalog

ShrinkFit Holders

High Precision Toolholding Solutions 35

SHRINKFIT PRO MACHINE

Features

ƒ Change 1/8" shanks in 2 seconds. 1" in 6 seconds
ƒ Flexible – Operates on 208V up to 480V

ƒ Automatic cooling cycle by compressed air

Features and Flexibility

This machine truly has it all; touchscreen simplicity,
state-of-the-art induction heating for fast tool changes,
and automatic cooling cycle using your shop air.

Easy-to-Use Touchscreen

Select your shank size and ShrinkPRO
sets heating duration

ACCESSORIES INCLUDED WITH MACHINE
Part No. Description QTY.
TIHS-6BT30 30 taper adapter 1
TIHS-6CAT40 40 taper adapter 1
TIHS-6C6 C6 taper adapter 1
TIHS-6HSK40 HSK40 adapter 1
TIHS-6HSK50 HSK50 adapter 1
TIHS-6H63/100 HSK63/100 adapter 1
TIHS-GLV insulated glove 1
Designed and built
in Indianapolis, IN. 20" wide x 20" deep x 37" tall Owners Manual 1

Part No. Description Tool Change Rating L x D x H Ship Wt.
TIHS-600 ShrinkPRO machine 2–6 seconds 3 phase, 480V, 20A 20"x 20"x 37" 84 lbs
For HSK32 Adapter order Part No. 00156. For HSK80 Adapter order Part No. 00160.

www.parlec.com | 1-800-866-5872 |
