Page 20 - Rex-Cut Call 714-897-1700

TYPE 27 GRINDING & BLENDING WHEELS

Manufactured with our signature abrasive materials, these Type 27 wheels are designed for grinding and blending in one step.

METALS
Stainless steel - Aluminum - Exotic metals
Mild steel - Brass
BENEFITS
Grind and finish in one step
Smooth, controlled grinding action
Non-loading on aluminum
Superior surface finishing on stainless steel and
aluminum
Long life and durability

SPECIFICATIONS COMMON APPLICATIONS & SPECS
Grit Type
A: Aluminum oxide APPLICATION ALUMINUM/ STAINLESS MILD
C: Silicon carbide NON FERROUS STEEL STEEL
Grain Size
24, 36: Coarse Grinding A24MTX A36GFX A24MTX
54, 80: Medium Blending A54GFX A36GFX A36GFX
Bonds
GFX: Blending: Flexible synthetic latex bond used for blending and finishing Finishing A80GFX A54GFX A36GFX
applications. It resists loading on aluminum and is resilient for a smooth, Beveling A36MTX A36GFX A24MTX
chatter-free operation on tanks, vessels, kitchen and food processing
equipment, trailers, and other fabrications. Weld Prep A36MTX A36GFX A24MTX
MTX: Grinding: Tough resin bond used for light or medium weld removal.
The resin bond provides a faster cut rate. It also resists loading on aluminum POPULAR IN-STOCK ITEMS
and offers excellent results on all non-ferrous materials.
DESCRIPTION PART #
4-1/2 X 1/8 X 7/8 A36 GFX 245002
AVAILABILITY
4-1/2 x 3/16 x 7/8 A36GFX 245022
DIAMETER THICKNESS ARBOR HOLES MAX RPM BOX QTY.
4-1/2 x 1/4 x 7/8 A24MTX 245051
4 1/8, 3/16, 1/4 5/8 15,300 10/25 4-1/2 x 1/4 x 7/8 A36GFX 245042

4-1/2 1/8, 3/16, 1/4 7/8 13,300 10/25 4-1/2 x 1/4 x 7/8 A54GFX 245043
5 3/16, 1/4 7/8 12,200 10/25 7 x 1/4 x 7/8 A36GFX 270042
7 3/16*, 1/4 7/8 8,500 10/25 7 x 1/4 x 5/8 - 11 A36GFX 270102
9 3/16*, 1/4 7/8 6,600 10/25 7 x 1/4 x 7/8 A54GFX 270043
*Available in GFX only Other items may be in stock. Please call to check availability

Available with 5/8 - 11 throw away adapters
Reusable adapter kits are available, see Page 31

In-stock item Angle Grinder

17 IMPROVE YOUR DAILY GRIND
