Page 17 - Techniks Catalog 2017

SlimFIT SBL6 Extended Reach Collet System

SlimFIT: Extreme precision, slim design and extended reach.

Features
• Maximum T.I.R. 0.0001" from taper to collet pocket
• Balanced to 25,000 RPM at G2.5
• .55" nose diameters

SlimFIT is the best collet & nut holder solution for
cutting tools from 3/32" up to 1/4" when cutting at
extended lengths.

12" tapered collet chuck

SlimFIT collets are longer and more powerful than ER collets and
provide better accuracy and performance at extended lengths.

Advantages of SlimFIT tool design

The drawbar tightening system eliminates collet nuts, saving time and money.
Powerful 4˚ taper collets provide improved performance holding tool shanks from
3/32" to 1/4" (3mm-6mm). Perform fast tool changes using just the T-wrench.

better tool balance than ER
T-wrench provided
more powerful and accurate than ER

You lose 10% of tool life for every .0001" of T.I.R.
SlimFIT Chucks offer excellent accuracy at extended lengths.

Built for Speed.

All Techniks products are backed by our 100% satisfaction guarantee!
