Parts for TAC Tools
Screws
Dimensions (in)
Shape Part Cat. No. Stock Applicable Tools
a øb c d e f
ASM6 d M6×1.0 .394 .709 12 3 Tooling Systems
øb a AJM5F d M5×0.5 .354 .512 .315 .079 TAC Cartridge PN-type
TAC Cartridge CP-type
f d AJM5 d M5×0.8 .354 .512 .315 .079 TAC Mills
c
ASM34S d M3 .189 .315 .197 .079 Tooling Systems
øb a ASM34L d .433 .315 TAC Cartridge CP-type
TAC Cartridge CE-type
f d ASM54 d M5×0.8 .354 .551 .354 .118 TAC Cartridge SP-type
c TAC Cartridge PNE-type
CHHM3.5-10 d M3.5×0.6 .236 .531 .394 .118 TAC Grooving & Parting Tools
CHHM4-10 M4×0.7 .276 .551 CGD-type
CHHM5-14 M5×0.8 .335 .748 .551 .157 CGW-type
CFGS-type
CHHM5-18 d .906 .709 CFGT-type
CHHM6-15 .827 .591 TAC Drills
øb a
d CHHM6-20 M6 .394 - .787 .197 Tooling Systems
f c CHHM6-25 1.22 .984 TAC Cartridge PN-type
TAC Cartridge CP-type
TAC Cartridge CE-type
TAC Cartridge SP-type
TAC Cartridge PNE-type
CM3×0.5×6 d M3×0.5 .217 .354 .236 .098 TAC Mills
CM3×0.5×10 .512 .394 TAC Mill PS-series
CM4×0.7×10 .551 TAC Grooving & Parting Tools
TungCut
CM4×0.7×12 d .630 .472
CM4×0.7×14 d M4×0.7 .276 .709 .551 .118
CM4×0.7×15 .748 .591
CM4×0.7×20 d .945 .787
CM4×0.7×20-MO-A d M4×0.7 .236 .945 .787 .118
CM5×0.8×8 .512 .315
CM5×0.8×10-A d .591 .394
CM5×0.8×12 d .669 .472
CM5×0.8×12-A d M5×0.8 .669 .472
CM5×0.8×14 d .709 .551
CM5×0.8×16 .335 .827 .630 .157
CM5×0.8×16-A d .827 .630
øb a
d CM5×0.8×18 .906 .709
f c CM5×0.8×20-A d M5×0.8 .984 .787
Hex. socket head screw CM5×0.8×25-A d M5×0.8 1.18 .984
(JISB1176)
CM5×15 M5 .787 .591
CM6×1×16-A d M6×1.0 .394 .866 .630 .197
CM6×1×20-A d M6×1.0 .394 1.02 .787 .197
CM6×1×25-A d M6×1.0 .394 1.22 .984 .197
CM6×1.0×40-A d M6×1.0 .394 1.81 1.58 .197
CM6×10 .630 .394
.827 .591
13 CM6×15 M6 .394 .866 .630 .197
CM6×16
CM6×20 1.02 .787
1.22 .984
CM6×25 d M6×1.0 .394 1.41 1.10 .197
Parts for TAC Tools CM8×1.25×20-A d M8×1.25 .512 1.30 .984 .236
CM6×30-S
M8×1.25
.236
.512 1.10 .787
CM8×1.25×25-A
d
M8×1.25
.512 1.42 1.18
.197
CM8×30H
d
M10
.315
CM10×30
.630 1.18 .787
CM10×30H
.236
M10×1.5
.630 1.50
CM12×30H
d
M16×2
CM16×40H d M12×1.75 .709 1.58 1.18 .315
.945 2.13 1.58
.394
d
C0.375X1.125H d 3/8-24UNF .562 1.50 1.125
C0.500X1.375H d 1/2-20UNF .750 1.876 1.375
SD06-A3 d M10x1.5 .630 2.756 2.362
