Page 989 - Tungaloy Catalog

Parts for TAC Tools
Screws
Dimensions (in)
Shape Part Cat. No. Stock Applicable Tools
a øb c d e T or f
FSHM8-30 d M8×1.25 .433 1.18 1.06 .197 TAC Mills
FSHM8-30H d
øb a
d FSHM10-40 d
f c M10 .551 1.58 1.44 .236
FSHM10-40H d
SHCM4-10 d M4×0.7 .551 .394 TAC Mills
øb a SHCM4-12 d .236 .630 .472 .118
d SHCM4-16 d .787 .630
f c
CTS-M6 d M6×1 .394 .984 .646 .157 TAC Toolholders
C-type (Use with KNMX inserts)
øb a TAC Grooving & Parting Tools
f d CTW-type
c
MCS520-2.5 d M5×0.8 .236 .098 TAC External Toolholders
Left-hand Right-hand MCS620-3 .787 .276 .276 M-type
thread thread d M6×1 .118 C-type
MCS625-3 d .394 .315
a a .984 TAC Internal Toolholders
d e MCS825-4 d .492 .256 M-type
f c f
MCS828-4 d M8×1 1.104 .472 .413 .157 TAC Grooving & Parting Tools
NDS-8A d 1.18 .453 .453 CTH-type
NDS-8S d M8×1.25 .787 .315 .315
Left-hand Right-hand DS-6T M6 .591 .236 .236 TAC Mills
T thread thread d
DS-6P d M6×1 .827 .276 .276 15IP
FDS-8ST d .787 .315
a a
d e FDS-8ST-18 M8×1 .709 .315 .236 T27
c d
DS-6 d M6×1 .591 .236 .236 .118 TAC Grooving & Parting Tools
DS-8 d M8×1.25 .630 .276 .276 .157 CTH-type
Left-hand Right-hand DS-8S d .512 .217 .217 TAC Threading Tools
thread thread TT-type
DS-10 d M10×1.5 1.02 .472 .197 TAC Mills
FDS-6Z d M6×0.75 .807 .394 .217 .118
a a
FDS-8 d 1.02 .394
d e
f c FDS-8S d M8×1 .787 .315 .157
FDS-8SS d .728 .315 .256

SSHM3-3 M3 .118 .059 TAC External Toolholders
SSHM3-6 .236 THC-type (1st Generation product)
SSHM4-4 d .157 Tooling Systems
TAC Cartridge PN-type
SSHM4-6 d .236 TAC Cartridge CP-type
SSHM4-8 d M4 .315 .079 TAC Cartridge CE-type
SSHM4-10 .394 TAC Cartridge SP-type
TAC Cartridge PNE-type
SSHM4-14 .551 TAC Internal Toolholders
Hex. socket screw (Flat end)(JISB1177) SSHM5-6 d .236 Stream Jet Bar mini
SSHM5-10 d M5 .394 .098
a 13
SSHM5-16 .630
f c SSHM6-12 d .472
SSHM6-16 M6 .630 .118
SSHM6-18 d .709
SSHM6-20 d .787
SSHM8-8 d .315
SSHM8-10 d .394 Parts for TAC Tools
SSHM8-12 d M8 .472 .157
SSHM8-14 d .551
SSHM8-16 d .630
SSHM8-18 d .709 .551

d : Stocked items.
: Stocked in Japan
13–5
