Sets • DRILLS
131

Heavy Duty High Speed Steel Jobbers Length Drill Sets
135° Split Point • Ground • Right Hand

Benefits: feAtures:
• Body and clearance are black & gold • Nitro drill with nitride surface
surface treated for maximum lubricity. treatment gives a hard
protective layer to the drill,
APPLiCAtiOns: which is measurably harder MoDeL #400N0115
• Recommended for use in stainless steel than high speed steel.
& other hard metal drilling.
[SeRieS 440N]
# Of Size MODeL ORDeR PRice MoDeL #400N29
PieceS Range caSe # # PeR Set
115 1/16" to 1/2" by 64ths, #1 to #60, A to Z Metal Index 400N0115 01-350-035 $362.47
15 1/16" to 1/2" by 32nds Metal Index 400N15 01-350-037† 82.41
21 1/16" to 3/8" by 64ths Metal Index 400N21 01-350-039† 74.67
21 1/16" to 1/4" by 64ths, 9/32" to 1/2" by 32nds Metal Index 400N21V 01-350-040† 95.91
26 A to Z Metal Index 400N26 01-350-041† 184.30
29 1/16" to 1/2" by 64ths Metal Index 400N29 01-350-042 155.32
60 #1 to #60 Metal Index 400N60 01-350-043† 117.48
29 1/16" to 1/2" by 64ths PAL Container 400NW29 01-350-044 161.75
†Ships direct from factory. MoDeL #400NW29
cobalt Jobber Length Bronze 135° Split Point Drill Sets
Ground • Right Hand

Heavy duty construction made to
type J aircraft specifications
Benefits: APPLiCAtiOns: feAtures:
• High red hardness of cobalt permits • Used for drilling in hard, tough materials • Straight shank.
speeds 30% greater than high speed such as stainless steel, titanium high • Metal index.
steel drills. temperature strength alloys. † Ships direct
# Of Size MODeL ORDeR PRice from factory. MoDeL #500A15
PieceS Range # # PeR Set
15 1/16" to 1/2" by 32nds 500A15 01-350-067 $129.71
29 1/16" to 1/2" by 64ths 500A29 01-350-071 193.88 MoDeL #500A29
Black Oxide High Speed Steel Jobbers Length Drill Sets
118° Drill Point • Ground • Right Hand

Benefits: feAtures:
• The surface treatment prevents • Black oxide surface treatment.
chip welding, improves chip flow, & • Straight shank.
increases abrasion resistance. • Metal index.
†Ships direct from factory.
APPLiCAtiOns:
• Designed for general purpose drilling.
• Effective on cast iron, steel & steel forging.
# Of Size MODeL ORDeR PRice
PieceS Range # # PeR Set MoDeL #200A15
15 1/16" to 1/2" by 32nds 200A15 01-350-010 $66.30 MoDeL #200A29
29 1/16" to 1/2" by 64ths 200A29 01-350-016 118.50
60 #1 to #60 200A60 01-350-017 93.88 MoDeL #200A60
29 Piece fractional Heavy Duty 135° Split Point
Black Oxide Jobbers Length Drill Set

Ground • Right Hand
Web construction is heavier than general purpose construction, making it
suitable for cotter pin hole drilling & cross hole drilling in heads of bolts

APPLiCAtiOns: feAtures: inCLudes:
• Effective in drilling stainless steel and • Split point reduces the thrust • Sizes: 1/16" to 1/2" by 64ths
other hard materials. requirements & minimizes walking.
†Ships direct from factory.
MODeL ORDeR PRice
# # PeR Set
400HD29 01-350-054 $141.63
