DRILLS • High Speed Steel Jobbers
136

Surface Treated High Speed Steel Jobbers Length Twist Drills QuanTiTy BreakS:
118° Point • Ground From The Solid • Straight Shank • Right Hand • Package Quantity: Less 10%
60+ Pcs.: Less 15%
General Purpose, Production Or Heavy Duty QuanTiTy Per Package

Size QuanTiTy
TTc PrODucTiOn
A thru L 12
Surface treatment increases abrasion resistance, M thru Z 6
nacHi
reducing the amount of chip welding & improving chip flow A thru N 10
O thru Z 5
Prices shown are per drill.
♦ See Page 135 For Applications & Features.

FOR STEEL FOR STEEL

generaL PurPOSe 118° POinT generaL PurPOSe 118° POinT
LeTTer SizeS 118° POinT [A3] [501] LeTTer SizeS 118° POinT [A3] [501]
DecimaL OveraLL OrDer Price OrDer Price DecimaL OveraLL OrDer Price OrDer Price
Size Size
DiameTer LengTH # eacH # eacH DiameTer LengTH # eacH # eacH
A .2340" 3-7/8" 01-003-001 $1.76 01-003-501 $2.91 N .3020" 4-3/8" 01-003-014 $2.58 01-003-514 $4.52
B .2380 4 01-003-002 1.76 01-003-502 2.91 O .3160 4-1/2 01-003-015 2.58 01-003-515 4.52
C .2420 4 01-003-003 1.76 01-003-503 2.91 P .3230 4-5/8 01-003-016 2.99 01-003-516 5.11
D .2460 4 01-003-004 1.76 01-003-504 2.91 Q .3320 4-3/4 01-003-017 2.99 01-003-517 5.11
E .2500 4 01-003-005 1.64 01-003-505 2.65 R .3390 4-3/4 01-003-018 3.11 01-003-518 5.42
F .2570 4-1/8 01-003-006 1.94 01-003-506 3.19 S .3480 4-7/8 01-003-019 3.28 01-003-519 5.81
G .2610 4-1/8 01-003-007 2.11 01-003-507 3.57 T .3580 4-7/8 01-003-020 3.81 01-003-520 6.57
H .2660 4-1/8 01-003-008 2.11 01-003-508 3.57 U .3680 5 01-003-021 3.81 01-003-521 6.57
I .2720 4-1/8 01-003-009 2.11 01-003-509 3.57 V .3770 5 01-003-022 3.88 01-003-522 6.88
J .2770 4-1/8 01-003-010 2.17 01-003-510 3.80 W .3860 5-1/8 01-003-023 4.05 01-003-523 7.12
K .2810 4-1/4 01-003-011 2.47 01-003-511 4.20 X .3970 5-1/8 01-003-024 4.93 01-003-524 8.64
L .2900 4-1/4 01-003-012 2.47 01-003-512 4.20 Y .4040 5-1/4 01-003-025 5.33 01-003-525 10.07
M .2950 4-3/8 01-003-013 2.58 01-003-513 4.85 Z .4130 5-1/4 01-003-026 5.69 01-003-526 10.27
Bright Finish High Speed Steel Jobbers Length Twist Drills QuanTiTy BreakS:
118° Point • Ground From The Solid • Straight Shank • Right Hand • General Purpose Package Quantity: Less 10%
60+ Pcs.: Less 15%
QuanTiTy Per Package
Size QuanTiTy
TTc PrODucTiOn
Bright finish drills can be used 1/64" thru 9/32" 12
in a wide range of materials 19/64" thru 1/2" 6
aPPLICatIONs: Features: PreciSiOn DOrmer
• Bright finish drills help increase chip • Right hand (clockwise rotation) cutting direction. 1/64" thru 19/64" 12 6
5/16" thru 1/2"
flow in soft materials. • Standard two flute design. Prices shown are per drill.
• Standard spiral, helical flutes.
teChNICaL Data: • Straight shanks correspond to the drill diameter.
• Cylindrically ground from the solid. • The jobbers length used for each of these drills is variable and is 1/64" to 1/32": Sold in
• 118° point angle and standard web thickness. determined by the specific drill diameter offering the best balance package quantity only.
• Bright finish. between overall drill rigidity and depth capacity for each drill diameter. Metric Sizes Available
♦ See Page 137 For Additional Applications. See Page 143

FOR NON-FERROUS FOR NON-FERROUS

FracTiOnaL SizeS [A1-USA] [R10P] FracTiOnaL SizeS [A1-USA] [R10P]
DecimaL OveraLL OrDer Price OrDer Price OrDer Price DecimaL OveraLL OrDer Price OrDer Price OrDer Price
Size Size
DiameTer LengTH # eacH # eacH # eacH DiameTer LengTH # eacH # eacH # eacH
1/64" .0156" 3/4" 01-001-601 $.94 01-001-101 $2.28 — — 17/64" .2656" 4-1/8" 01-001-617 $1.82 01-001-117 $2.65 01-300-317 $3.92
1/32 .0312 1-3/8 01-001-602 .70 01-001-102 1.55 01-300-302 $1.77 9/32 .2812 4-1/4 01-001-618 1.88 01-001-118 2.90 01-300-318 4.04
3/64 .0469 1-3/4 01-001-603 .70 01-001-103 1.05 01-300-303 1.79 19/64 .2969 4-3/8 01-001-619 2.17 01-001-119 3.33 01-300-319 4.70
1/16 .0625 1-7/8 01-001-604 .83 01-001-104 1.11 01-300-304 1.64 5/16 .3125 4-1/2 01-001-620 2.41 01-001-120 3.64 01-300-320 5.18
5/64 .0781 2 01-001-605 .83 01-001-105 1.11 01-300-305 1.65 21/64 .3281 4-5/8 01-001-621 2.58 01-001-121 3.95 01-300-321 5.77
3/32 .0938 2-1/4 01-001-606 .83 01-001-106 1.11 01-300-306 1.65 11/32 .3438 4-3/4 01-001-622 2.99 01-001-122 4.44 01-300-322 6.40
7/64 .1094 2-5/8 01-001-607 .83 01-001-107 1.11 01-300-307 1.74 23/64 .3594 4-7/8 01-001-623 3.35 01-001-123 5.05 01-300-323 7.23
1/8 .1250 2-3/4 01-001-608 .83 01-001-108 1.17 01-300-308 1.69 3/8 .3750 5 01-001-624 3.41 01-001-124 5.18 01-300-324 7.35
9/64 .1406 2-7/8 01-001-609 .88 01-001-109 1.30 01-300-309 1.88 25/64 .3906 5-1/8 01-001-625 3.81 01-001-125 5.92 01-300-325 8.45
5/32 .1562 3-1/8 01-001-610 .88 01-001-110 1.36 01-300-310 1.92 13/32 .4062 5-1/4 01-001-626 3.93 01-001-126 6.04 01-300-326 8.65
11/64 .1719 3-1/4 01-001-611 1.00 01-001-111 1.47 01-300-311 2.08 27/64 .4219 5-3/8 01-001-627 4.40 01-001-127 6.65 01-300-327 9.62
3/16 .1875 3-1/2 01-001-612 1.11 01-001-112 1.61 01-300-312 2.33 7/16 .4375 5-1/2 01-001-628 4.58 01-001-128 7.03 01-300-328 10.04
13/64 .2031 3-5/8 01-001-613 1.17 01-001-113 1.92 01-300-313 2.56 29/64 .4531 5-5/8 01-001-629 5.10 01-001-129 7.64 01-300-329 11.27
7/32 .2188 3-3/4 01-001-614 1.41 01-001-114 2.03 01-300-314 2.84 15/32 .4688 5-3/4 01-001-630 5.33 01-001-130 8.20 01-300-330 11.89
15/64 .2344 3-7/8 01-001-615 1.41 01-001-115 2.16 01-300-315 3.07 31/64 .4844 5-7/8 01-001-631 5.63 01-001-131 8.57 01-300-331 12.57
1/4 .2500 4 01-001-616 1.53 01-001-116 2.28 01-300-316 3.22 1/2 .5000 6 01-001-632 5.69 01-001-132 9.61 01-300-332 12.45
