Shell Mill • CUTTERS
371

M42 Cobalt Roughing Shell End Mills APPLICATIONS:
Heavy Duty • Right Hand • Round Tooth • For general purpose roughing operations
for applications where larger diameter
end milling cutter is preferred.
• Designed as arbor mounted cutters for
machine tools.
• Well suited for a variety of ferrous and
[D43R] non-ferrous materials.
HolE
# oF
FaCE
SizE DiaMEtER tEEtH WiDtH oRDER PRiCE FeATureS:
EaCH
#
2" 3/4" 8 2" 10-304-128 $109.13 • Right hand knuckle tooth design removes material
2-1/4 1 8 2 10-304-144 107.28 more efficiently, produces finer roughing finishes
2-1/2 1 8 1-5/8 10-304-160 115.55 and holds closer tolerances than other similar cutters.
2-3/4 1 10 2 10-304-176 170.83 • Slots cut into back end of shell body are used to engage
3 1-1/4 10 2 10-304-192 173.28 driving lugs on the arbor, providing a positive drive and
3-1/2 1-1/4 10 2 10-304-224 235.20 prevents any possibility of slippage during use.
4 1-1/2 10 2-1/4 10-304-256 350.73
4-1/2 1-1/2 12 2-1/4 10-304-264 503.40 TeChNICAL DATA:
5 1-1/2 12 2-1/4 10-304-284 618.16 • Manufactured from M42 cobalt steel.
5-1/2 2 14 2-1/4 10-304-336 690.92 • Ground from solid.
6 2 14 2-1/4 10-304-390 818.16 • Bright finish.
M42 Cobalt Shell End Mills
Right Hand • Heavy Duty
APPLICATIONS:
• For milling operations where a larger diameter
TiN Coated Available, end milling cutter is preferred.
Please Call • Designed as arbor mounted cutters for
machine tools.
[D43] • Slots cut into back end of shell body are used
HolE
# oF
SizE lEngtH DiaMEtER tEEtH oRDER PRiCE to engage driving lugs on the arbor, providing a
EaCH
#
oF Cut
positive drive and preventing any possibility of
1-1/4" 1" 1/2" 8 10-305-088 $68.05 slippage during use.
1-1/2 1-1/8 1/2 8 10-305-096 71.15 • For heavy duty and rough milling applications.
2 1-3/8 3/4 10 10-305-128 103.54
2-1/2 1-5/8 1 10 10-305-160 122.43 FeATureS:
2-3/4 1-5/8 1 12 10-305-180 143.54 • Sized and proportioned to afford a good
3 1-3/4 1-1/4 12 10-305-192 166.07 cutting range and ample rigidity.
3-1/2 1-7/8 1-1/4 12 10-305-216 245.29 • Right hand helical tooth and roughing
4 2-1/4 1-1/2 14 10-305-256 364.51 tooth designs.
4-1/2 2-1/4 1-1/2 14 10-305-264 445.50
5 2-1/4 1-1/2 14 10-305-284 486.00
6 2-1/4 2 14 10-305-390 736.38
Heavy Duty Slab Milling Cutters
45° Left Hand High Helix • Right Hand Cut
APPLICATIONS: FeATureS:
• For surface milling and other operations where only peripheral teeth are required. • Sized and proportioned to afford a
• For heavy stock removal and slab cuts on plain flat surfaces. good cutting range & ample rigidity.
• For use in a variety of ferrous and non-ferrous materials.
• Best suited for surface milling where the cutter width is greater than the workpiece. TeChNICAL DATA:
• Manufactured from high speed steel.
[E2] • Ground from solid.
FaCE HolE # oF oRDER PRiCE • Bright and black finish.
SizE
WiDtH DiaMEtER tEEtH # EaCH
2-1/2" 2" 1" 8 10-010-020 $99.90
3 3 1-1/4 8 10-010-040 180.89
3 4 1-1/4 8 10-010-060 234.51
3 6 1-1/4 8 10-010-080 367.22
4 2 1-1/2 8 10-010-100 202.22
4 3 1-1/2 8 10-010-120 298.69
4 4 1-1/2 8 10-010-140 421.75
