CUTTERS • Concave, Convex & Corner Rounding
372

Concave High Speed Steel Milling Cutters Convex High Speed Steel Milling Cutters

APPLICATIONS: APPLICATIONS:
• For milling male • For milling female
half circles. half circles.
FeATureS: FeATureS:
• Teeth are form relieved • Teeth are form relieved
and straight gashed. and straight gashed.
• Cutting surfaces may • Cutting surfaces may
be resharpened on be resharpened on
face without changing face without changing
contour or form for contour or form for
increased tool life. increased tool life.

CiRCLe CutteR HoLe oRDeR PRiCe CiRCLe CutteR HoLe oRDeR PRiCe
DiaMeteR DiaMeteR DiaMeteR # eaCH DiaMeteR DiaMeteR DiaMeteR # eaCH
1/16" 2-1/4" 1" 10-272-002 $60.71 1/16" 2-1/4" 1" 10-273-002 $75.89
3/32 2-1/4 1 10-272-004 63.24 3/32 2-1/4 1 10-273-004 75.89
1/8 2-1/4 1 10-272-008 63.24 1/8 2-1/4 1 10-273-008 75.89
5/32 2-1/4 1 10-272-010 75.89 5/32 2-1/4 1 10-273-010 75.89
3/16 2-1/4 1 10-272-012 75.89 3/16 2-1/4 1 10-273-012 75.89
1/4 2-1/2 1 10-272-016 88.54 1/4 2-1/2 1 10-273-016 78.82
5/16 2-3/4 1 10-272-020 101.19 5/16 2-3/4 1 10-273-020 95.06
3/8 2-3/4 1 10-272-024 101.19 3/8 2-3/4 1 10-273-024 95.06
7/16 3 1 10-272-028 126.49 7/16 3 1 10-273-028 107.78
1/2 3 1 10-272-032 151.79 1/2 3 1 10-273-032 125.17
5/8 3-1/2 1-1/4 10-272-040 177.09 5/8 3-1/2 1-1/4 10-273-040 162.24
3/4 3-3/4 1-1/4 10-272-048 215.04 3/4 3-3/4 1-1/4 10-273-048 231.75
7/8 4 1-1/4 10-272-056 202.39 7/8 4 1-1/4 10-273-056 261.92
1 4-1/4 1-1/4 10-272-064 316.24 1 4-1/4 1-1/4 10-273-064 331.50
1-1/4 4 1-1/4 10-272-080 404.79 1-1/4 4 1-1/4 10-273-080 382.47
1-1/2 4-1/4 1-1/4 10-272-096 531.29 1-1/2 4-1/4 1-1/4 10-273-096 605.62
1-3/4 5-1/2 1-1/4 10-272-112 569.24 1-3/4 5-1/2 1-1/4 10-273-112 733.69
2 6 1-1/2 10-272-128 860.19 2 6 1-1/2 10-273-128 758.99

Data On Gears Left Hand Corner Rounding
Comparative sizes Of Gear teeth For series e18 & e188 Involute Gear Cutters Quarter Circle High Speed Steel
• Use for comparison of gear tooth sizes only, should not be used for
actual measurement. Milling Cutter
Gear Cutters
Pages 373-374

APPLICATIONS:
• For radius milling.
FeATureS:
• May be easily
resharpened by grinding
cutting faces without
changing form.

CUttInG FLUID
♦ Limited Supply. PAGEs 1470-1492 saFety GLasses
PAGEs 1594-1600
CiRCLe CutteR HoLe oRDeR PRiCe
DiaMeteR DiaMeteR DiaMeteR # eaCH
sOUrCe: MetaL CUttInG tOOL HanDBOOK, 7tH eDItIOn UsCtI 1/2" 4-1/4" 1-1/4" 10-070-080 $96.15
