P. 521

MaxiMill profiling system
                                                                                                                   B194
                                                                                              System overview






          Milling cutters for profiling, chamfering and slot profiles

          ○ For common machining tasks






































          Material groups

           P     ●
           M     ○
           K     ○
           N     ○
           S
           H

          Possible applications






            Profile milling  Chamfering  T-slot milling  Slot milling
                                                        (circlip)





        Detailed information

                                                                                                                     Milling / Profile milling
                        Pitch                            Ø range                           Inserts

                                                                                         SD..0903..
                                                                              R06E../R08E../R10D../ R12D../R16D..
                                                             -
                                                                                   SP..05../CP..06../CP..09..
                                                                                       TC 11../TC 16..
