MaxiMill profiling system
B199
CNF
l 1
h6
Ø d 1 Ø d A
DIN 1835B
Ø d 3
a
l 2
d 1 Type, l 1 l 2 d 3 d A a z n
[mm] description [mm] [mm] [mm] [mm] [mm] [Nm]
17.5 C NF.17.R.01 80 25 8.5 16 8 1 2 1.2 SP.. 0502.. E01
20.5 C NF.20.R.01 85 30 10.5 16 9 1 2 1.2 CP.. 0603.. E02
24.0 C NF.23.R.01 95 32 12.5 25 10 1 2 1.2 CP.. 0603.. E02
31.0 C NF.30.R.02 105 40 16 25 12 2 4 1.2 CP.. 0603.. E02
38.5 C NF.37.R.02 115 50 20 32 16 2 4 3.2 CP.. 09T3.. E03
48.0 C NF.47.R.02 125 60 26 32 20 2 4 3.2 CP.. 09T3.. E03
E01 76913 11149541 8095010200
Milling / Profile milling B276
