Circlip grooving – internal
C97
Modular system – internal, assembly size 20

T max
T max
Ø D s Ø D s
Matching products see right-hand side.

L R L R
d A D min s T max
Type, Type,
[mm] description [mm] [mm] [mm] description
20 R MSS-I20R90-1.5D-N 25 1.95 5.00 R MSS-I20R05-GX09-1 GX09-1.. C153
C207 C210 25 2.25 5.00 R MSS-I20R05-GX09-1 GX09-1.. C153
5.00
GX09-2.. C153
2.75
R MSS-I20R05-GX09-2
25
25 3.25 5.00 R MSS-I20R05-GX09-2 GX09-2.. C153
25 R MSS-I20R90-2.5D-N 25 0.60 0.75 R MSS-I20R02-GX09-1 GX09-1..R/L C153
C208 25 0.80 0.94 R MSS-I20R02-GX09-1 GX09-1..R/L C153
25
R MSS-I20R02-GX09-1
GX09-1..R/L C153
0.90
1.04
C213 25 1.00 1.14 R MSS-I20R02-GX09-1 GX09-1..R/L C153
25 1.20 1.34 R MSS-I20R02-GX09-1 GX09-1..R/L C153
25 1.40 1.53 R MSS-I20R02-GX09-1 GX09-1..R/L C153
25 1.70 1.82 R MSS-I20R02-GX09-1 GX09-1..R/L C153
L R L R
d A D min s T max
Type, Type,
[mm] description [mm] [mm] [mm] description
20 L MSS-I20L90-1.5D-N 25 1.95 5.00 L MSS-I20L05-GX09-1 GX09-1.. C153
C207 C210 25 2.25 5.00 L MSS-I20L05-GX09-1 GX09-1.. C153
GX09-2.. C153
L MSS-I20L05-GX09-2
5.00
2.75
25
25 3.25 5.00 L MSS-I20L05-GX09-2 GX09-2.. C153
25 L MSS-I20L90-2.5D-N 25 0.60 0.75 L MSS-I20L02-GX09-1 GX09-1..R/L C153
C208 25 0.80 0.94 L MSS-I20L02-GX09-1 GX09-1..R/L C153
25
L MSS-I20L02-GX09-1
GX09-1..R/L C153
0.90
1.04
C213 25 1.00 1.14 L MSS-I20L02-GX09-1 GX09-1..R/L C153
25 1.20 1.34 L MSS-I20L02-GX09-1 GX09-1..R/L C153
25 1.40 1.53 L MSS-I20L02-GX09-1 GX09-1..R/L C153
25 1.70 1.82 L MSS-I20L02-GX09-1 GX09-1..R/L C153
