Thread milling
C256
Milling tool system MSS-TC

Full profile Full profile
D G
metric ISO 60° Whitworth 55°

MSS-I32R-TC16-2 MSS-I32N-TC16-3 MSS-I32R-TC16-2
TC16-2 I 2,0 ISO TC16-2 I 3,0 ISO TC16-3 I 4,0 ISO TC16-2 EI 11W

Type,
D G D G
Bgr. description [mm] [inch]
3
32 1.5D M82 x x x R 2 / 4 x
MSS-I32R90-1.5D M85 x x x
M90 x x x R3 x
1
M95 x x x R3 / 4 x
1
M100 x x x R3 / 2 x
3
M105 x x x R3 / 4 x
M110 x x x R4 x
Ø32
M115 x x x
M120 x x x
1
M125 x x x R4 / 2 x
M130 x x x
M135 x x x
48
M140 x x x R5 x
M145 x x x
Ø44
1
M150 x x x R5 / 2 x
M155 x x
M160 x x
M165 x x R6 x
M170 x x
2.5D M175 x x
MSS-I32R90-2.5D M180 x x
M185 x x
M190 x x
M195 x x
M200 x x
Ø40 M205 x x
M210 x x
M215 x x
M220 x x
80 M225 x x
M230 x x
M235 x x
Ø59 M240 x x
M245 x x
M250 x x
↓ ↓ ↓
M300 x x Parting and grooving / Technical information

Bgr. = assembly size
