Evolution Angle Heads
Quotation Request Sheet 173
QUOTATION REQUEST SHEET
ANGLE HEAD INFORMATION
*Head Style: Fixed 90° 0°-90° Adjustable Special Fixed Angle Dual Output Automatic Tool Change Flange Mount
*Output Toolholder: _______________________________ *Dimension: __________________________________
Internal Coolant RequiredPressure: ____________
Through Through Directly from the
Orientation Orientation Machine Spindle
Pin Pin and Tool through the Tool
ANGLE HEAD DIMENSIONS
A: _______________________ B: ________________________ C: _____________________ D: _________________________
E: _______________________ E1: _______________________ E2: ____________________ E3: ________________________
