Numertap 700
®

184 Torque-controlled Tapping

C
Taper Size
Adapter
Retention Knob Ø2.750" (sold separately)
(sold separately)

Adjustable 0-1/4"
9/16" Tension
Stroke TA and TT

TORQUE-CONTROLLED TAPPING
FROM #6 - 3/4" FERROUS MATERIAL AND #6 - 1" NON-FERROUS MATERIAL

ƒ Large work range eliminates the need to purchase several units.

ƒ Radial float improves thread quality and tap life.
ƒ Precalibrated torque control prevents tap breakage when bottom tapping.

ƒ Free-floating tension stroke ensures thread size and quality.

ƒ Adjustable compression stroke ensures depth control.
ƒ Rugged alloy steel construction for long trouble-free service life.

ƒ Through-spindle coolant option available gets coolant into the hole and flushes chips.

ƒ Quick-change system allows taps to be quickly exchanged.

Part Number
Part Number with Coolant Fed Shank C Approx. Weight
B40-70TA5 - BT40 5.90 7 lbs.
C40-70TA5C C40 6.28 7 lbs.
C50-70TA5C C50 5.46 11 lbs.
Other sizes available upon request. Coolant-through for up to 250 lbs. of pressure.

CAPACITY

Ferrous Non-Ferrous Positive Drive Capacity
#10 - 3/4 #10 - 1 #6 - 1 5/8
1/1 - 1/2 NPT 1/16 - 1/2 NPT 1/16 -1 1/4 NPT
M5 - M20 M5 - M25 M3.5 - M33

TORQUE-CONTROLLED FOR BOTTOM TAPPING, TENSION

AND COMPRESSION ON CNC MACHINES.
