easylock
TUNGAL O Y

Electrical Nut-Clamp Torque Control Device

• Ensures controlled (proper) clamping of cutting tools
• Maintains collet chuck accuracy
• Easy clamping and unclamping of cutting tools
• Handy set for various collet chuck sizes
• Main spindle taper #50
• Suitable for main shank standards #40, #50, HSk 63, HSk 100

Table Model

Specifications
Euro Motor: 1 phase 200/240V 50/60 HZ 1 kn
Weight: Table model - 85 kG.
Trolley (optional) - 15 kgf.

Tooling Systems
12

Easy Lock Unit
Electrical Nut-Clamp Torque Control Device
Cat. No. Accessories
Standard Optional
TP50 AD 40 EASY EASY LOCk TROLLEY
WREnCH ER16 EASY LOCk TP40 AD 30 EASY
WREnCH ER20 EASY LOCk TP50 AD HSk 63 EASY
WREnCH ER25 EASY LOCk TP50 AD HSk 100 EASY
EASY LOCK T.C EU
WREnCH ER32 EASY LOCk
WREnCH ER40 EASY LOCk WREnCH ER50 EASY LOCk
WREnCH TG100 OPEn EASY

12–9
