END MILLS • Corner Rounding
98

2 Flute Solid Carbide Double End Corner Rounding End Mills

Two cutting ends for
increased productivity
TiAlN & AlTiN Coated Availabe,
Please Call
TolERanCES:
Radius: +.001" / -.001"
Shank EnD ovERall oRDER PRiCE
RaDiuS
DiaMETER DiaMETER lEngTh # EaCh
0.01" 1/8" 0.105" 1-1/2" 20-512-510 $24.91
0.015" 1/8" 0.095" 1-1/2" 20-512-515 24.91
0.02" 1/8" 0.085" 1-1/2" 20-512-520 24.91
0.025" 1/8" 0.075" 1-1/2" 20-512-525 24.91
Corner rounded Corner Corner round 0.031" 1/8" 0.063" 1-1/2" 20-512-530 24.91
0.035" 1/8" 0.055" 1-1/2" 20-512-535 28.56
0.039" 1/8" 0.047" 1-1/2" 20-512-540 24.91
APPLiCAtiOns: feAtures: 0.047" 3/16" 0.094" 2" 20-512-545 33.01
• Produces uniform radius finish on • Bright finish tools. 0.05" 3/16" 0.088" 2" 20-512-550 32.70
outside corners. 0.062" 3/16" 0.064" 2" 20-512-555 32.70
• Effective on steel, stainless steel, 0.072" 1/4" 0.106" 2-1/2" 20-512-560 33.97
hi-temperature alloys, cast iron & 0.078" 1/4" 0.094" 2-1/2" 20-512-565 39.66
non-ferrous materials. 0.093" 1/4" 0.064" 2-1/2" 20-512-570 48.96
• Machines HRc <48. 0.1" 1/4" 0.050" 2-1/2" 20-512-575 39.66
0.118" 5/16" 0.077" 2-1/2" 20-512-580 44.37
0.125" 5/16" 0.063" 2-1/2" 20-512-585 44.37
0.156" 3/8" 0.063" 2-1/2" 20-512-590 56.91
Solid Carbide Extended Reach Double End Corner Rounding End Mills
2 Or 4 Flutes

Extra long solid carbide corner rounders
for extended reach applications
TolERanCES:
Radius: ±.0015"
4 FluTE
Shank ovERall # oF oRDER PRiCE
RaDiuS
DiaMETER lEngTh FluTES # EaCh
Corner radius .010" 1/4" 3" 4 20-512-400 $90.00
aCCurate to ±.0015" .015" 1/4" 3" 4 20-512-401 90.00
.020" 1/4" 3" 4 20-512-402 90.00
Benefits: feAtures: .031" 1/4" 3" 4 20-512-403 90.00
• Having the radius center line on • The radius center lines are on the shank diameter ±.0015". .046" 1/4" 3" 4 20-512-404 90.00
the shank diameter allows for • The length from the end of the tool to the radius center line .062" 1/4" 3" 4 20-512-405 90.00
machining close to or even flush is .010", also ±.0015". .010" 3/8" 4" 4 20-512-409 110.00
with other features. †Ships direct from factory. .015" 3/8" 4" 4 20-512-410 110.00
• The 5° flare, typical helps prevent .020" 3/8" 4" 4 4 20-512-411 110.00
3/8"
.031"
4"
20-512-412 110.00
gouging the part. 2 FluTE .046" 3/8" 4" 4 20-512-413 110.00
Shank ovERall # oF oRDER PRiCE .062" 3/8" 4" 4 20-512-414 110.00
APPLiCAtiOns: RaDiuS DiaMETER lEngTh FluTES # EaCh .010" 1/2" 4" 4 20-512-417 125.00
• Machining corner radii in hard to reach .031" 1/4" 3" 2 20-512-406 $90.00 .015" 1/2" 4" 4 20-512-418 125.00
places in various part materials. .046" 1/4" 3" 2 20-512-407 90.00 .020" 1/2" 4" 4 20-512-419 125.00
• 2 flutes, very free machining for .062" 1/4" 3" 2 20-512-408 90.00 .031" 1/2" 4" 4 20-512-420 125.00
non-ferrous part materials. .093" 3/8" 4" 2 20-512-415 110.00 .046" 1/2" 4" 4 20-512-421 125.00
• 4 flutes to machine ferrous and most .125" 3/8" 4" 2 20-512-416 110.00 .062" 1/2" 4" 4 20-512-422 125.00
part materials. .156" 1/2" 4" 2 20-512-425 125.00 .093" 1/2" 4" 4 20-512-423 125.00
.187" 1/2" 4" 2 20-512-426 125.00 .125" 1/2" 4" 4 20-512-424 125.00
