END MILLS • Ball, 2 Flute
102

2 Flute Micrograin Solid Carbide Ball Nose Single End Mills
Center Cutting • Right Hand • Uncoated, TiN Coated Or TiCN Coated • 30° Helix

For HigH Temp
tin coated For cAsT iron exoTic Alloys
uncoated
For non-Ferrous For sTeel For sTAinless

ticn coated uNCoaTEd uNCoaTEd TiN CoaTEd TiCN CoaTEd
[150] [150T] [150C]
ShaNk FluTE ovErall ordEr PriCE ordEr PriCE ordEr PriCE ordEr PriCE
SizE
diaMETEr lENgTh lENgTh # EaCh # EaCh # EaCh # EaCh
1/32" 1/8" 5/64" 1-1/2" — — 20-415-001 $26.67 — — — —
APPLICATIONS: 3/64 1/8 7/64 1-1/2 — — 20-415-005 26.67 — — — —
• For milling radius bottom slots, fillets 1/16 1/8 3/16 1-1/2 20-605-004 $9.26 20-415-009 20.81 — — — —
and special contours. 5/64 1/8 15/64 1-1/2 — — 20-415-011 21.30 — — — —
• For deep slotting applications and for 3/32 1/8 9/32 1-1/2 — — 20-415-015 21.30 — — — —
aluminum and non-ferrous materials. 3/32 1/8 3/8 1-1/2 20-605-006 8.91 — — — — — —
M.A. Ford 7/64 1/8 21/64 1-1/2 — — 20-415-021 21.30 — — — —
• For most ferrous metal applications. 1/8 1/8 3/8 1-1/2 — — 20-415-025 19.83 20-455-077 $22.17 20-455-059 $22.17
1/8 1/8 1/2 1-1/2 20-605-008 8.13 — — — — — —
5/32 3/16 1/2 2 — — 20-415-029 28.40 — — — —
5/32 3/16 9/16 2 20-605-010 12.31 — — — — — —
3/16 3/16 9/16 2 — — 20-415-035 27.66 20-455-079 30.97 — —
3/16 3/16 5/8 2 20-605-012 12.35 — — — — — —
TolEraNCES: 7/32 1/4 5/8 2-1/2 20-605-014 17.77 20-415-041 36.72 — — — —
ruShMorE 1/4 1/4 3/4 2-1/2 20-605-016 17.50 20-415-045 33.78 20-455-082 37.82 20-455-064 37.82
Cutter Diameter 9/32 5/16 3/4 2-1/2 — — 20-415-049 44.92 — — — —
1/32" thru 1/4": +.000" / -.002" 5/16 5/16 13/16 2-1/2 20-605-020 21.62 20-415-051 46.27 20-455-083* 42.23 20-455-065 51.77
9/32" thru 3/4": +.000" / -.003" 3/8 3/8 7/8 2-1/2 20-605-024 28.83 20-415-057 53.36 20-455-085 59.73 20-455-067 59.73
Shank Diameter: +.0000" / -.0005" 7/16 7/16 7/8 2-1/2 20-605-028 43.81 — — — — — —
M.a. Ford 7/16 7/16 1 2-3/4 — — 20-415-063 69.03 20-455-087 77.37 — —
Cutter Diameter 1/2 1/2 1 3 20-605-032 48.40 20-415-067 87.28 20-455-089 97.80 20-455-071 97.80
1/64" thru 3/64": +.000" / -.002" 5/8 5/8 1-1/4 3-1/2 — — 20-415-073 131.74 — — — —
7/8" thru 1": +.000" / -.003"
*Limited Supply.
2 Flute Micrograin Solid Carbide Ball Nose Single End Mills
Center Cutting • Right Hand • Uncoated Or TiCN Coated • 40° High Performance Helix

TolEraNCES:
Cutter Diameter
uncoated 1/32" thru 1/4": +.000" / -.002"
9/32" thru 3/4": +.000" / -.003"
Shank Diameter: +.0000" / -.0005"
uNCoaTEd TiCN CoaTEd
ticn coated SizE ShaNk FluTE ovErall ordEr PriCE ordEr PriCE
EaCh
#
EaCh
#
APPLICATIONS: 1/32" diaMETEr lENgTh lENgTh 08-600-100 $16.26 08-601-100 $20.24
3/32"
1/8"
1-1/2"
• For milling radius bottom slots, fillets and special contours. 1/16" 1/8" 3/16" 1-1/2" 08-600-101 15.01 08-601-101 18.73
• For deep slotting applications and for aluminum and non-ferrous materials. 3/32" 1/8" 3/8" 1-1/2" 08-600-102 15.75 08-601-102 19.68
• 10% cobalt premium micrograin tungsten carbide. 1/8" 1/8" 1/2" 1-1/2" 08-600-103 13.89 08-601-103 16.39
• Provides higher shearing action. 5/32" 3/16" 9/16" 2" 08-600-104 20.34 08-601-104 23.89
• Higher rake and helix. 3/16" 3/16" 5/8" 2" 08-600-105 17.50 08-601-105 20.72
• Improved chip ejection allows use of higher feeds and speeds on stainless steel 1/4" 1/4" 3/4" 2-1/2" 08-600-107 23.16 08-601-107 27.00
and heat-treated materials. 3/8" 3/8" 1" 2-1/2" — — 08-601-110 43.38
• Center cutting allows for 3 axis profile milling, plunging and ramping. 1/2" 1/2" 1" 3" — — 08-601-112 76.91
2 Flute Stub length alTiN Coated Solid Carbide
Ball Nose double End Mills
Two cutting Center Cutting • Right Hand • 30° Helix ShaNk FluTE ovErall ordEr PriCE
ends SizE diaMETEr lENgTh lENgTh # EaCh
APPLICATIONS: 1/32" 1/8" 1/16" 1-1/2" 20-078-202 $25.83
• For milling radius bottom slots, fillets & special contours. 3/64" 1/8" 3/32" 1-1/2" 20-078-203 25.83
AlTiN Coating 1/16" 1/8" 1/8" 1-1/2" 20-078-204 20.97
• Provides high heat resistance. 3/32" 1/8" 3/16" 1-1/2" 20-078-206 20.97
• For dry high speed machining as well as hard machining. 1/8" 1/8" 1/4" 1-1/2" 20-078-208 19.18
• Thermal threshold of 900°C or 1,652°F. 5/32" 3/16" 5/16" 2" 20-078-210 30.64
• For milling of titanium, stainless steel & high temperature alloys. 3/16" 3/8" 5/16" 2" 20-078-212 26.27
7/32" 1/4" 3/8" 2-1/2" 20-078-214 41.42
FeATureS: 1/4" 1/4" 1/2" 2-1/2" 20-078-216 37.78
TolEraNCES: • Black coating color. 5/16" 5/16" 1/2" 2-1/2" 20-078-220 52.49
Cutting Diameter: +.0000" / -.002" • 2 flutes provide the greatest amount of flute space for chip 3/8" 3/8" 9/16" 2-1/2" 20-078-224 57.26
Shank Diameter: +.0000" / -.0001" to -.0005" carrying capacity. 7/16" 1/2" 9/16" 2-3/4" 20-078-228 72.45
1/2"
89.65
20-078-232
5/8"
3"
1/2"
