Trepanning Tools • DRILLS
201

Magnetic Drill Press r401 Magnetic Drill Press
Portable Hole Making System Portable Holemaking System

Achieve burr free holes in a fraction of the Variable speed
time it takes using traditional twist drills motor
APPLICATIONS: FeATureS:
• Ideal for plant maintenance and steel erection. • Automatic coolant.
• Supplied quick change arbor provides easy • Clutch and overload protection.
conversion from cutter to drills. • Lightweight, only 32.19 lbs.
FeATureS: • Easy system for fitting 1/2" drill chuck.
• Powerful, compact and lightweight with wide
high-density magnet for greater stability.
Models With Cutter Capacity SPecificationS:
Up To 4" Available, Please Call Motor ................................1,100 Watts
Cutter Capacity .....................2-37/64"
SPecificationS: No Load Speed .................... 610 RPM
Motor ...................................960 Watts Magnetic Strength ................ 1,653 lbs
Cutter Capacity ............. 1-3/8" H.S.S. Internal Arbor (Weldon Style)
1-1/2" Carbide Tipped Diameter ....................................... 3/4"
Twist Drill Capacity .......................1/2" Depth Of Cut ....................................2"
Magnetic Strength ...............2,200 lbs. INCLudeS: Electrical ............................... 50-60 Hz INCLudeS:
Shipping Weight ....................40.5 lbs. Weight .................................... 32.2 lbs
• Plastic carrying case. • Carry case.
MoDel orDer Price • 1/2" drill chuck. MoDel orDer Price • Drill chuck.
# # eacH • Safety strap and safety guard. # # eacH • Accessories.
PB35 26-035-532 $1,147.49 • Cutting fluid. R401 26-035-560 $759.99
Swivel Base Model #HMD904S Magnetic Drill Press

Precisely lines up the pilot BeNeFITS:
with the holes center location • Uses a quick one stroke handle for
MoDel orDer Price locking and unlocking the swivel.
# # eacH • Rear positioned controls are easily
HMD904S 26-037-988 $1,125.00 accessible and ergonomically designed.
• Safety switch indicator tells operator
SPecificationS: when the lift sensor is engaged.
Electrical Systems ......................................................1115V, 50/60 Hz - 9A, 1035W
Motor ...................................................................8A,920W (115V), 4A, 920W (230V) APPLICATIONS:
Hole Capacity .......................................................... 7/16" - 1-1/2" (12mm - 38mm) • Uses Rotabroach annular cutters for
Diameter Depth .........................................................................................2" (50mm) 1-1/2" x 2" cutting.
Cutter / Mount ......................................... Rotabroach “12,000 Series” / 3/4" Shank
Dimensions ............................................................19-3/8" H x 7-3/4" W x 11-8/8"L FeATureS:
Magnet Redesigned!
Base .........................................................................................3-1/8"W x 6-9/16"L • NEW slot drive arbor, for fast and easy
Strength 1" Plate ....................................................................Dead Lift 1,750 lbs. / changeout of drill arbor and accessories.
Drillpoint Breakaway Back 995 lbs., Forward 640 lbs. • NEW pilot light for low light conditions
Strength 3/8" Plate ..................................................................Dead Lift 1310 lbs. /
Drillpoint Breakaway Back 710 lbs., Forward 485 lbs. & greater hole accuracy.
Swivel Area .................................................................................1-1/8"W x 1-3/8"L • NEW two stage magnet-engages
Net Weight ................................................................................................... 31.9 lbs. full power when motor is turned on.
Shipping Weight ............................................................................................. 45 lbs. • Feed handles can be switched to either side.
chuck adapters
BeNeFITS:
Expand your machine for • Allows 1/2" x 20 threaded drill
greater shop productivity chuck to be placed into any 3/4"
weldon arbor.
• Allows the use of twist drills and
MoDel orDer Price
# # eacH plain shank cutters.
18Y170 26-035-700 $34.58
Pilot Pins for annular cutters

DePtH orDer Price
BranD range
of cut # eacH
7/16" Only 1" 26-035-003* $18.59
7/16" Only 2" 26-035-004* 23.06 ♦ Purchasing The Same Brand Pilot
1/2" to 4" 1" 26-035-001* 12.20 Pin And Cutter Is Recommended.
1/2" to 4" 2" 26-035-002* 18.17
7/16" - 2" for M35 Cutters & 5/8", 1" 26-036-885 5.99 BranD range DePtH MoDel orDer Price
11/16" Carbide Tipped Cutters of cut # # eacH
7/16" - 2" for M35 Cutters & 5/8", 1/2" to 19/32" & 13mm - 15mm 1" 10531 26-037-980 $11.56
11/16" Carbide Tipped Cutters 2" 26-036-886 5.99 5/8" to 2-3/8" & 19mm - 52mm 1 10527 26-037-976 11.56
3/4" - 2" Carbide Tipped Cutters 1" 26-036-887 6.32 1/2" to 19/32" & 13mm - 15mm 2" 10532 26-037-981 12.42
3/4" - 2" Carbide Tipped Cutters 2" 26-036-888 6.54 5/8" to 2-3/8" & 19mm - 52mm 2 10528 26-037-978 12.42
*Can also be used with TTC Production high speed steel cutters. 3/4" to 2-3/8" & 19mm - 52mm 3 24131 26-037-979 16.09
