Plain Saws • CUTTERS
379

Cobalt Plain Coarse Tooth Saw Blades

Benefits: APPLiCAtiOns: feAtures:
• Used for better abrasion and shock • Recommended for medium depth • Manufactured from MAT43 (5%) cobalt.
resistance and the toughness to handle slitting and slotting operations, cutting • Keyways on widths .040" and up.
interrupted cuts in materials up to 42Rc. thick sections, profiles, extrusions and
• Perform well in free machining of heavy wall tubing.
medium tensile strength steels, cast
iron, hard and abrasive plastics,
aluminum, brass, bronze and other
non-ferrous alloys. Other Sizes Available,
Please Call
CuTTer FaCe arBor hole # oF order PriCe CuTTer FaCe arBor hole # oF order PriCe
diaMeTer WidTh diaMeTer TeeTh # eaCh diaMeTer WidTh diaMeTer TeeTh # eaCh
1-3/4" 0.031" 1/2" 44 10-222-000 $38.92 3" 0.125" 1" 40 10-222-036 $101.81
1-3/4" 0.063" 1/2" 32 10-222-002 51.46 4" 0.020" 1" 64 10-222-038 75.69
1-3/4" 0.125" 1/2" 32 10-222-004 169.74 4" 0.025" 1" 64 10-222-040 72.17
2" 0.031" 5/8" 48 10-222-006 41.11 4" 0.031" 1" 64 10-222-042 67.94
2" 0.040" 5/8" 48 10-222-008 48.66 4" 0.040" 1" 64 10-222-044 80.99
2" 0.047" 5/8" 36 10-222-010 45.90 4" 0.047" 1" 64 10-222-046 78.50
2" 0.063" 5/8" 36 10-222-012 52.99 4" 0.063" 1" 64 10-222-048 92.32
2" 0.078" 5/8" 36 10-222-014 91.19 4" 0.078" 1" 48 10-222-050 112.98
2" 0.094" 5/8" 36 10-222-016 93.39 4" 0.094" 1" 48 10-222-052 108.75
2" 0.125" 5/8" 36 10-222-018 180.05 4" 0.125" 1" 48 10-222-054 137.51
3" 0.020" 1" 64 10-222-020 48.10 5" 0.031" 1" 80 10-222-056 125.83
3" 0.025" 1" 64 10-222-022 54.27 5" 0.063" 1" 64 10-222-058 149.34
3" 0.031" 1" 64 10-222-024 51.67 5" 0.125" 1" 48 10-222-060 299.86 ToleranCeS:
3" 0.040" 1" 64 10-222-026 61.05 6" 0.047" 1-1/4" 80 10-222-062 167.20 Diameter
3" 0.047" 1" 64 10-222-028 59.01 6" 0.063" 1-1/4" 80 10-222-064 184.99 1"-2": ±.004"
3" 0.063" 1" 40 10-222-030 66.66 6" 0.078" 1-1/4" 80 10-222-066 229.37 2-1/4"-4": ±.006"
3" 0.078" 1" 40 10-222-032 76.00 6" 0.094" 1-1/4" 64 10-222-068 236.76 5"-6": ±.008"
3" 0.094" 1" 40 10-222-034 76.96 6" 0.125" 1-1/4" 64 10-222-070 354.89 Arbor Hole: +.0002" / +.0008"
Cobalt Plain Medium Tooth Saw Blades

Other Sizes Available,
Please Call
FaCe hole # oF order PriCe FaCe hole # oF order PriCe
Size Size
WidTh diaMeTer TeeTh # eaCh WidTh diaMeTer TeeTh # eaCh
1" 0.008" 3/8" 80 10-214-000 $28.71 2" 0.020" 5/8" 100 10-214-080 $29.38
1" 0.010" 3/8" 80 10-214-002 27.44 2" 0.025" 5/8" 100 10-214-082 35.30
1" 0.012" 3/8" 80 10-214-004 26.42 2" 0.031" 5/8" 100 10-214-084 32.85
1" 0.014" 3/8" 64 10-214-006 26.12 2" 0.040" 5/8" 100 10-214-086 42.54
1" 0.016" 3/8" 64 10-214-008 25.50 2" 0.047" 5/8" 64 10-214-088 40.35
1" 0.018" 3/8" 64 10-214-010 24.84 2" 0.063" 5/8" 64 10-214-090 47.49
1" 0.020" 3/8" 64 10-214-012 25.00 2" 0.078" 5/8" 64 10-214-092 68.75
1" 0.025" 3/8" 64 10-214-014 29.48 2" 0.094" 5/8" 64 10-214-094 70.79
1" 0.031" 3/8" 64 10-214-016 30.04 2" 0.125" 5/8" 64 10-214-096 120.22
1" 0.040" 3/8" 64 10-214-018 35.55 2-1/2" 0.020" 5/8" 120 10-214-098 33.51
1" 0.047" 3/8" 40 10-214-020 31.52 2-1/2" 0.025" 5/8" 120 10-214-100 39.68
1" 0.063" 3/8" 40 10-214-022 35.91 2-1/2" 0.031" 5/8" 120 10-214-102 37.24
1" 0.078" 3/8" 40 10-214-024 51.67 2-1/2" 0.040" 5/8" 120 10-214-104 47.94 Benefits:
1" 0.094" 3/8" 40 10-214-026 55.54 2-1/2" 0.047" 5/8" 120 10-214-106 46.16 • Used for better abrasion and shock
1" 0.125" 3/8" 40 10-214-028 94.00 2-1/2" 0.063" 5/8" 72 10-214-108 53.25 resistance and the toughness to handle
1-1/4" 0.025" 1/2" 80 10-214-032 31.93 2-1/2" 0.078" 5/8" 72 10-214-110 73.75 interrupted cuts in materials up to 42Rc.
1-1/4" 0.031" 1/2" 80 10-214-034 29.89 2-1/2" 0.094" 5/8" 72 10-214-112 74.16 • Perform well in medium to high tensile
1-1/4" 0.040" 1/2" 48 10-214-036 35.20 2-1/2" 0.125" 5/8" 72 10-214-114 124.30 strength steels, hard non-ferrous alloys
1-1/4" 0.047" 1/2" 48 10-214-038 33.41 3" 0.020" 1" 160 10-214-116 39.28 and abrasive plastics.
1-1/4" 0.063" 1/2" 48 10-214-040 39.68 3" 0.025" 1" 128 10-214-118 46.26
1-1/4" 0.078" 1/2" 48 10-214-042 57.23 3" 0.031" 1" 128 10-214-120 43.56 APPLiCAtiOns:
1-1/4" 0.094" 1/2" 48 10-214-044 58.55 3" 0.040" 1" 128 10-214-122 53.15 • Recommended for shallow depth slitting
1-1/4" 0.125" 1/2" 48 10-214-046 104.72 3" 0.047" 1" 128 10-214-124 51.21 and slotting operations, cutting medium
1-1/2" 0.025" 1/2" 80 10-214-048 31.52 3" 0.063" 1" 80 10-214-126 59.27 heavy sections, profiles, slotting screw,
1-1/2" 0.031" 1/2" 80 10-214-050 29.13 3" 0.078" 1" 80 10-214-128 78.04 bolts and nuts.
1-1/2" 0.040" 1/2" 48 10-214-052 36.88 3" 0.094" 1" 80 10-214-130 79.16
1-1/2" 0.047" 1/2" 48 10-214-054 35.09 3" 0.125" 1" 80 10-214-132 137.00 feAtures:
1-1/2" 0.063" 1/2" 48 10-214-056 42.54 4" 0.020" 1" 160 10-214-134 66.26 • Manufactured from MAT43 (5%) cobalt.
1-1/2" 0.078" 1/2" 48 10-214-058 59.52 4" 0.025" 1" 160 10-214-136 62.89 • Keyways on widths .040" and up.
1-1/2" 0.094" 1/2" 48 10-214-060 61.21 4" 0.031" 1" 160 10-214-138 58.76
1-1/2" 0.125" 1/2" 48 10-214-062 107.83 4" 0.040" 1" 128 10-214-140 71.31
1-3/4" 0.025" 1/2" 90 10-214-064 33.00 4" 0.047" 1" 128 10-214-142 68.86
1-3/4" 0.031" 1/2" 90 10-214-066 30.65 4" 0.063" 1" 128 10-214-144 82.88
1-3/4" 0.040" 1/2" 90 10-214-068 38.66 4" 0.078" 1" 80 10-214-146 113.95 ToleranCeS:
1-3/4" 0.047" 1/2" 56 10-214-070 36.72 4" 0.094" 1" 80 10-214-148 109.61 Diameter
1-3/4" 0.063" 1/2" 56 10-214-072 44.73 4" 0.125" 1" 80 10-214-150 181.12 1"-2": ±.004"
1-3/4" 0.078" 1/2" 56 10-214-074 62.38 5" 0.031" 1" 160 10-214-152 87.16 2-1/4"-4": ±.006"
1-3/4" 0.094" 1/2" 56 10-214-076 64.06 5" 0.063" 1" 128 10-214-154 109.87 5"-6": ±.008"
1-3/4" 0.125" 1/2" 56 10-214-078 111.81 5" 0.125" 1" 100 10-214-156 213.60 Arbor Hole: +.0002" / +.0008"
