CUTTERS • Slotting Saws
382

High Speed Steel Screw Slotting Saws

Cutter FaCe Hole orDer PriCe Cutter FaCe Hole orDer PriCe
Diameter WiDtH Size # eaCH Diameter WiDtH Size # eaCH
60 teetH [E13A] 72 teetH (Cont.) [E13]
2-1/4" .010" 5/8" 10-217-010 $17.60 2-3/4" .051" 1" 10-215-051 $16.63
2-1/4" .012" 5/8" 10-217-012 17.28 2-3/4" .057" 1" 10-215-057 17.58
2-1/4" .014" 5/8" 10-217-014 16.14 2-3/4" .064" 1" 10-215-064 17.95
2-1/4" .016" 5/8" 10-217-016 14.19 2-3/4" .072" 1" 10-215-072 19.33
2-1/4" .018" 5/8" 10-217-018 14.14 2-3/4" .081" 1" 10-215-081 19.78
2-1/4" .020" 5/8" 10-217-020 12.31 2-3/4" .091" 1" 10-215-091 21.13
2-1/4" .023" 5/8" 10-217-023 13.54 2-3/4" .102" 1" 10-215-102 25.73
2-1/4" .025" 5/8" 10-217-025 12.31 2-3/4" .114" 1" 10-215-114 29.00
2-1/4" .028" 5/8" 10-217-028 13.54 2-3/4" .128" 1" 10-215-128 30.62
2-1/4" .032" 5/8" 10-217-032 13.94 2-3/4" .144" 1" 10-215-144 38.49
2-1/4" .036" 5/8" 10-217-036 15.75 2-3/4" .162" 1" 10-215-162 40.67
2-1/4" .040" 5/8" 10-217-040 14.33 2-3/4" .182" 1" 10-215-182 46.17
2-1/4" .045" 5/8" 10-217-045 15.42 90 teetH [E13B]
2-1/4" .051" 5/8" 10-217-051 15.42 1-3/4" .008" 5/8" 10-219-008 $18.45
2-1/4" .057" 5/8" 10-217-057 16.51 1-3/4" .010" 5/8" 10-219-010 17.02
2-1/4" .064" 5/8" 10-217-064 17.58 1-3/4" .012" 5/8" 10-219-012 16.50
APPLICATIONS: 72 teetH [E13] 1-3/4" .014" 5/8" 10-219-014 15.30
• Used for milling slots in screw and bolt heads, brass 2-3/4" .010" 1" 10-215-010 $19.69 1-3/4" .016" 5/8" 10-219-016 15.30
tubing, piston ring grooves or similar operations. 2-3/4" .012" 1" 10-215-012 18.95 1-3/4" .018" 5/8" 10-219-018 14.36
2-3/4" .014" 1" 10-215-014 17.60 1-3/4" .020" 5/8" 10-219-020 12.23
2-3/4" .016" 1" 10-215-016 16.14 1-3/4" .023" 5/8" 10-219-023 13.82
2-3/4" .018" 1" 10-215-018 14.19 1-3/4" .025" 5/8" 10-219-025 13.82
2-3/4" .020" 1" 10-215-020 12.29 1-3/4" .028" 5/8" 10-219-028 13.82
2-3/4" .023" 1" 10-215-023 13.85 1-3/4" .032" 5/8" 10-219-032 12.42
2-3/4" .025" 1" 10-215-025 12.29 1-3/4" .036" 5/8" 10-219-036 14.50
2-3/4" .028" 1" 10-215-028 12.29 1-3/4" .040" 5/8" 10-219-040 12.86
2-3/4" .032" 1" 10-215-032 14.36 1-3/4" .045" 5/8" 10-219-045 12.86
2-3/4" .036" 1" 10-215-036 14.76 1-3/4" .051" 5/8" 10-219-051 12.86
Saw Arbors 2-3/4" .040" 1" 10-215-040 14.36 1-3/4" .057" 5/8" 10-219-057 16.68
Pages 380-381 2-3/4" .045" 1" 10-215-045 15.74 1-3/4" .064" 5/8" 10-219-064 17.20
High Speed Steel Screw Slotting Saws

APPLICATIONS:
• Used for milling slots, screw & bolt heads, brass
tubing, piston rings or similar operations.
FeATureS:
• M2 material.
• Supplied with standard keyway slot.
†Ships direct from factory. stock materials cutting fluids r8 stub arbors
PAGES 1481-1492
PAGE 794
PAGES 1444-1461

Cutter FaCe Hole orDer PriCe Cutter FaCe Hole orDer PriCe Cutter FaCe Hole orDer PriCe
Diameter WiDtH Size # eaCH Diameter WiDtH Size # eaCH Diameter WiDtH Size # eaCH
90 teetH 60 teetH 72 teetH
1-3/4" .008" 5/8" 10-220-002 $23.01 2-1/4" .010" 5/8" 10-220-036 $21.93 2-3/4" .010" 1" 10-220-076 $25.86
1-3/4 .010 5/8" 10-220-004 20.22 2-1/4 .016 5/8" 10-220-042 20.49 2-3/4 .014 1" 10-220-080 21.81
1-3/4 .012 5/8" 10-220-006 19.58 2-1/4 .018 5/8" 10-220-044 17.58 2-3/4 .018 1" 10-220-084 19.43
1-3/4 .016 5/8" 10-220-010 18.18 2-1/4 .020 5/8" 10-220-046 16.86 2-3/4 .020 1" 10-220-086 17.73
1-3/4 .020 5/8" 10-220-014 16.87 2-1/4 .025 5/8" 10-220-050 16.86 2-3/4 .025 1" 10-220-090 16.80
1-3/4 .025 5/8" 10-220-018 16.43 2-1/4 .028 5/8" 10-220-052 16.86 2-3/4 .028 1" 10-220-092 16.80
1-3/4 .028 5/8" 10-220-020 16.43 2-1/4 .032 5/8" 10-220-054 20.14 2-3/4 .032 1" 10-220-094 20.71
1-3/4 .032 5/8" 10-220-022 17.10 2-1/4 .036 5/8" 10-220-056 19.58 2-3/4 .036 1" 10-220-096 21.32
1-3/4 .036 5/8" 10-220-024 18.18 2-1/4 .040 5/8" 10-220-058 20.65 2-3/4 .040 1" 10-220-098 20.71
1-3/4 .040 5/8" 10-220-026 16.80 2-1/4 .045 5/8" 10-220-060 22.28 2-3/4 .045 1" 10-220-100 22.73
1-3/4 .045 5/8" 10-220-028 17.73 2-1/4 .051 5/8" 10-220-062 21.12 2-3/4 .051 1" 10-220-102 23.99
1-3/4 .051 5/8" 10-220-030 17.73 2-1/4 .057 5/8" 10-220-064 22.58 2-3/4 .057 1" 10-220-104 25.39
1-3/4 .057 5/8" 10-220-032 20.91 2-1/4 .064 5/8" 10-220-066 25.39 2-3/4 .064 1" 10-220-106 25.94
1-3/4 .064 5/8" 10-220-034 23.71 2-1/4 .072 5/8" 10-220-068 27.26 2-3/4 .072 1" 10-220-108 27.90
2-1/4 .081 5/8" 10-220-070 28.66 2-3/4 .081 1" 10-220-110 28.54
2-1/4 .091 5/8" 10-220-072 29.26 2-3/4 .091 1" 10-220-112 30.49
2-1/4 .102 5/8" 10-220-074 31.30 2-3/4 .102 1" 10-220-114 33.78
2-3/4 .114 1" 10-220-116 39.70
2-3/4 .128 1" 10-220-118 44.19
2-3/4" .144 1" 10-220-120* 47.41
2-3/4 .162 1" 10-220-122 50.61
2-3/4 .182 1" 10-220-124 57.45
*Limited Supply.
