Band Saws • MACHINERY
639

7" x 12" Horizontal / Vertical Wet Band Saw

Features:
• Large 10" x 12" in feed table assembly extends the support area.
• Multi-position blade guides enhance use in vertical position by increasing the
throat capacity from 4" to 8".
• Tool-less quick lock vise with preset mitering positions at 15°, 30° & 45°. COOLANT
SYSTEM
• Improved height and width of stand with built-in storage cabinet and chip tray.
• Micro adjustable tool-less material stop for accurate set-up and repeatability.
• Blade drive is a belt to sealed, hardened and ground gear drive system. LISTED
MOTOR
• Blade wheels are made from flanged cast iron for increased durability.
• Adjustable ball bearing blade guides.
• Cast mounted adjustable hydraulic down feed.
• Auto shut-off after cut.
SPecificationS: BI-METAL
Cutting Capacity ..................................................................................... 7"W x 12"D BLADE
Round Cutting Capacity @ 90° ...............................................................................7"
Round Cutting Capacity @ 45° ...............................................................................5"
Rectangle Cutting Capacity @ 90° ........................................ 4" x 11" / 7" x 10-1/4" MATERIAL
Rectangle Cutting Capacity @ 45° ................................................................. 6" x 4" STOP
Square Cutting Capacity @ 90° ...................................................................... 7" x 7"
Square Cutting Capacity @ 45° ...................................................................... 5" x 5"
Throat Depth ..........................................................................................................7"
Head Movement .....................................................................................................0°
Vise Swivels ..........................................................................................................45°
Blade Speeds ..................................................................... 86, 132, 178, 260 SFPM
Blade Wheel Diameter ...................................................................................11-3/4"
Blade Length ........................................................................................................93"
Blade Size............................................................................ 3/4"W x 0.032"T x 93"L
Bed Height ....................................................................................................22-1/4"
Coolant Capacity ..........................................................................................1 Gallon ADJUSTABLE HYDRAULIC
DOWNFEED
Motor ....................................................................................3/4 HP, 115/230V, 1 PH
Overall Dimensions ....................................................................48"L x 17"W x 44"H MODEL #HVBS-712D
Weight .......................................................................................................... 418 lbs.

Includes:
M42 Band SaW BladeS • Complete coolant system.
teetH order Price • Four 8" rubber wheels for ease of movement.
lenGtH WidtH tHickneSS
Per incH # eacH
7'9" 3/4" .035" 4/6 26-032-034 $49.22
7'9" 3/4" .035" 5/8 26-032-036 49.22 Band SaW
7'9" 3/4" .035" 6/10 26-032-038 49.22 Model order Price
7'9" 3/4" .035" 8/12 26-032-040 49.22 # # eacH
7'9" 3/4" .035" 10/14 26-032-042 49.22 HVBS-712D 87-116-786 $1,379.00
8" x 14" Geared Head Horizontal / Vertical Band Saw
FLOOD
COOLANT
Features:
• Heavy duty geared head transmission for quick speed changes.
• Easy accessible control panel for operator use.
• Hydraulic down feed.
• Portable on wheels.
• Hardened and ground worm gears.
• Mitres at 45°.
• Quick action vise.
• Enclosed coolant system.

RAPID
Model order Price VISE
# # eacH Band Saw Blades
HBS-814GH 87-115-339 $2,199.00 Start On Page 403
SPecificationS:
Cutting Capacity ......................................................................................8"W x 14"D
Round Cutting Capacity @ 90° ...............................................................................8"
Round Cutting Capacity @ 45° ........................................................................ 6-1/2"
Rectangle Cutting Capacity @ 90° .................................................14" x 8", 2" x 14" AUTOMATIC
Rectangle Cutting Capacity @ 45° .............................................. 6-1/2" x 6", 2" x 7" SHUT-OFF
Vise Swivels .......................................................................................................... 45°
Blade Size...............................................................................3/4"W x .035"T x 97"L
Blade Wheel Diameter ..........................................................................................12"
Blade Speeds ............................................................................135, 197, 256 SFPM
Bed Height ...........................................................................................................26"
Motor ............................................................... 1HP, 1 PH, 115/230V, Prewired 115V
Overall Dimensions ...............................................................51-1/2" x 18-1/8" X 44" HYDRAULIC
Shipping Weight ............................................................................................363 lbs. DOWNFEED
