MACHINERY • Band Saw & Cold Saw
640

8.26" x 6.69" Horizontal/Vertical Band Saw

The BS-210M horizontal band saw from Baileigh Industrial will be a great performer in your shop, and will quickly become
one of your favorite tools. A good mix of features and benefits, plus an outstanding price make this saw a winner.
Features:
• Incrementally adjustable speed from 66~280 FPM through the use of an AC
inverter drive. This will allow the operator to gain cut quality and blade life.
• Two options for the operator to control the descent: manually using a trigger
switch and handle or it can be switched to utilize a hydraulic descent cylinder
normally seen on more expensive models
• When using the hydraulic descent feature, you can control the descent pressure
for perfect cuts.
• Automatically stop the blade when the cut is finished.
• Fluid filled blade tension devise.
†Ships direct from factory.
SpeCifiCationS:
Horsepower ............................................................ 1.5 HP
Voltage .......................................................................110V
Capacity
Round (90° / 45° / 60°) .........................7" / 4.72" / 2.75"
Rectangular (90°) ........................................ 8.26" x 6.69"
Square (90° / 45° / 60°).........................7" / 4.33" / 2.36"
Blade Size......................................83"L x .035"W x .75"H
Blade Speed .............................................. 66 ~ 280 FPM
Blade Guide ..............................................Carbide / Roller
Miter Angle ...........................................................0° ~ 60°
Miter Adjustment ...........................................Swivel Head
Table Height ................................................................. 35"
Descent Control..................................................Hydraulic
Return .................................................................... Manual
Drive .......................................................................... Gear
Shipping Dimensions.........................60"L x 44"W x 48"H
Shipping Weight ................................................... 444 lbs.
Model order priCe
# # eaCH
BS-210M 87-114-213 $2,595.00
Bench Model Cold Saw
Cutting Head Swivels 45° For Miter Cuts
It may be compact, but this premium bench cold saw has big-time cutting power and speed so you can cut your workload
down to size and save valuable time! Great for cutting metal, the saw proves its worth every day thanks to its 1 HP motor,
bronze worm gear and hardened ground worm screw gear box. A self-centering vise securely holds the workpiece in place
as you cut for improved accuracy. For miter cuts, the saw blade can be manually adjusted from 0 to 45° to the left.
The elongated control handle has a spring-loaded safety trigger switch to start or stop the machine. Heavy cast iron base
provides extra stability. Includes a 8.85" (225mm) blade for sawing solid steel materials.
Cut through solid metal sheets or
thick tubing in mere seconds
Features:
• Self-centering vise has dual jaws for SpeCifiCationS:
burr-free cuts. Cutting Capacity
• Sturdy oil bath gear box design. Round at 90° ......................................................... 2-1/2"
• Magnetic starter with overload protection. Round at 45° ................................................................2"
• Control handle has built-in Square at 90° ......................................................... 2-1/4"
Square at 45° ......................................................... 1-1/2"
spring loaded trigger switch. Blade Size..................................8.85"L x 1.25"W x .078"T
• Flood coolant system with removable Blade Speed ........................................................52 SFPM
coolant tray for easy cleaning. Maximum Vise Opening ...................................... 2-11/16"
• Adjustable work stop for repetitive Motor .......................................................1 HP, 115V, 1 PH
cutting lengths. Weight (Net/Gross) ..................................84 lbs. / 140 lbs.
• Full blade guard for safety.
• Main power switch has a Cold Saw
FLOOD Model order priCe
COOLANT removable safety key. deSCription
SELF-CENTERING †Ships direct from JET USA warehouse. # # eaCH
VISE 8.85" Blade Size F225 87-100-930 $999.00
STOP

replaCeMent BladeS
Model order priCe
deSCription
# # eaCH
2 - 32 / 180 Teeth 579000 87-100-954* CALL
2 - 32 / 120 Teeth 579002 87-100-956* CALL
Model #F225 Model #579000 *Please call for updated price.
