MACHINERY • Band Saws
644

18" Metal/Wood Vertical Band Saw

aPPlIcatIOns: SpecificationS:
• Specially designed to effectively Throat Depth .........................................................................................................18"
cut a variety of materials including Cutting Capacity
wood, plastic, composites, ferrous Round .................................................................................................................12"
and non-ferrous metals. Rectangle ...........................................................................................12" x 17-3/4"
Square ................................................................................................................12"
Features: Miter Capacity .......................................................................................................90°
• Unitized welding steel frame Table Dimensions ........................................................................................ 19" x 19"
construction. Maximum Blade Length ......................................................................................137"
• Cast blade wheels. Maximum Blade Width ..............................................................................3/16" to 1"
• Large ground cast iron work table Blade Thickness ...............................................................................................0.035"
Blade Speed ................................................. 45, 65, 90, 110, 155, 215, 3,000 SFPM
that tilts up to 45°. Voltage .......................................................................................................115V/230V
• Adjustable precision bearing HP .......................................................................................................................1-1/2
blade guides. Overall Dimensions .................................................................... 80"H x 29"W x 24"D
• Hinged wheel for easy accessibility Weight (Net/Gross) ........................................................................ 424 lbs. / 490 lbs.
and fast blade changing
and adjustments. Band SaW
• 4" dust port and rip fence. Model order price
†Ships direct from factory. # # each
83118 87-115-502 $1,899.99
Includes:
• Rip fence.
• Miter gauge.
• Chip blower. M42 replaceMent Band SaW BladeS
• Chip chute. teeth order price
• Extra wide speed range. length Width thickneSS per inch # each
• (1) Wood & (1) metal blade. 11'5" 3/4" .035" 6/10 26-032-132 $64.84
11'5" 1" .035" 4/6 26-032-134 72.88
11'5" 1" .035" 5/8 26-032-136 72.88
11'5" 1" .035" 6/10 26-032-138 72.88
18" Metal/Wood Vertical Band Saw

Features: Includes:
• Exclusive quick release, precision T-square style rip fence. • Miter gauge.
• Built-in cutting height scale. • Fence and rail assembly.
• Extra large 19" x 19" cast iron table. • 4" dust chute.
• Convenient speed changes with no tools required. • 3/4" carbon steel blade.
• Ball bearing guide system reduces friction for longer blade life. • Chip tray.
• Lower blade wheel brush and dust collection port. • Tension release lever.
• Heavy duty gear box.
• Roller bearing guides. SpecificationS:
• Easy to view blade Cutting Capacity Height ........................................................................................12"
tracking adjustment window. Blade Size............................................................................. 3/4"W x .035"T x 137"L
• Made in Taiwan. Blade Speeds
† Ships direct from Low ........................................................................................... 80, 150, 265 SFPM
JET USA warehouse. High ............................................................................... 1,000, 1,800, 3,200 SFPM
Throat Depth ..................................................................................................18-3/8"
Blade Length .......................................................................................................137"
Blade Width ..................................................................................1/8"-1-1/2" (Wood)
Table Size .................................................................................................... 19" x 19"
Table Tilt .................................................................................................R-45°, L-10°
Table Height @ 90° .........................................................................................37-1/2"
Cutting Speeds
Metal ........................................................................................ 80, 150, 265 SFPM
Wood ............................................................................ 1,000, 1,800, 3,200 SFPM
Motor ................................................................1HP, 115/230V, 1 PH, Prewired 115V
Dimensions .................................................................................40"L x 42"W x 81"H
Gross Weight ................................................................................................. 448 lbs.
Band SaW
Model order price
deScription
# # each
18-3/8" Throat Capacity VBS-18MW 87-115-512 $2,599.00

M42 Band SaW BladeS
teeth order price
length Width thickneSS
per inch # each
Model #VBS-18MW 11'5" 3/4" .035" 6/10 26-032-132 $64.84
11'5" 1" .035" 4/6 26-032-134 72.88
Additional Band Saw Blades 11'5" 1" .035" 5/8 26-032-136 72.88
Starting On Page 403 11'5" 1" .035" 6/10 26-032-138 72.88
