Page 1282 - Ceratizit Catalog
P. 1282
Grade description
F285
Solid carbide tools for drilling
SCPP415 HC-P15 ● ○ ○
Specification:
Grain size: submicron / 0.7 µm | Hardness: HV 1600 | Type of coating: Ti Al C N | Coating
30
specification: multi-layer
Recommended application:
Good combination of carbide and coating for universal application
SCPP420
HC-P20 ● ○ ○
Specification:
Grain size: submicron / 0.7 µm | Hardness: HV 1600 | Type of coating: Ti Al C N | Coating
30
specification: multi-layer
Recommended application:
First choice for carbide and coating for deep hole drills. Additionally optimised chip control.
SCPP425 HC-P25 ● ○ ○ ○
Specification:
Grain size: submicron / 0.7 µm | Hardness: HV 1600 | Type of coating: Ti Al C N | Coating
30
specification: multi-layer
Recommended application:
Good combination of carbide and coating, for the machining of steels
SCPP430 HC-P30 ● ○ ○ ○ ○
Specification:
Grain size: fine / < 1 µm | Hardness: HV 1570 | Type of coating: Ti Al C N | Coating speci-
30
fication: multi-layer
Solid carbide tools / Drilling Good combination of carbide and coating for universal application.
Recommended application:
