W0606, coated
F458
HSC reamers for through holes

H

SCPP625

Ø d 3 Ø d A
Ø d 1
l 2
l 3
l 1
HA

d 1 Type, d A d 3 l 1 l 2 l 3 z
[mm] description [mm] [mm] [mm] [mm] [mm] Material
3.97 HSC-DR.UN.0606.0397H7.29.IK.HA 6 3.73 75 12 35 6 W0606039750
3.98 HSC-DR.UN.0606.0398H7.29.IK.HA 6 3.74 75 12 35 6 W0606039850
3.99 HSC-DR.UN.0606.0399H7.29.IK.HA 6 3.75 75 12 35 6 W0606039950
4.0 HSC-DR.UN.0606.0400H7.29.IK.HA 6 3.76 75 12 35 6 W0606040050
4.01 HSC-DR.UN.0606.0401H7.29.IK.HA 6 3.77 75 12 35 6 W0606040150
4.02 HSC-DR.UN.0606.0402H7.29.IK.HA 6 3.78 75 12 35 6 W0606040250
4.03 HSC-DR.UN.0606.0403H7.29.IK.HA 6 3.79 75 12 35 6 W0606040350
4.97 HSC-DR.UN.0606.0497H7.27.IK.HA 6 4.67 75 12 35 6 W0606049750
4.98 HSC-DR.UN.0606.0498H7.27.IK.HA 6 4.68 75 12 35 6 W0606049850
4.99 HSC-DR.UN.0606.0499H7.27.IK.HA 6 4.69 75 12 35 6 W0606049950
5.0 HSC-DR.UN.0606.0500H7.27.IK.HA 6 4.7 75 12 35 6 W0606050050
5.01 HSC-DR.UN.0606.0501H7.27.IK.HA 6 4.71 75 12 35 6 W0606050150
5.02 HSC-DR.UN.0606.0502H7.27.IK.HA 6 4.72 75 12 35 6 W0606050250
5.03 HSC-DR.UN.0606.0503H7.27.IK.HA 6 4.73 75 12 35 6 W0606050350
5.97 HSC-DR.UN.0606.0597H7.26.IK.HA 6 5.61 75 12 35 6 W0606059750
5.98 HSC-DR.UN.0606.0598H7.26.IK.HA 6 5.62 75 12 35 6 W0606059850
5.99 HSC-DR.UN.0606.0599H7.26.IK.HA 6 5.63 75 12 35 6 W0606059950
6.0 HSC-DR.UN.0606.0600H7.26.IK.HA 6 5.64 75 12 35 6 W0606060050
6.01 HSC-DR.UN.0606.0601H7.26.IK.HA 6 5.65 75 12 35 6 W0606060150
6.02 HSC-DR.UN.0606.0602H7.26.IK.HA 6 5.66 75 12 35 6 W0606060250
6.03 HSC-DR.UN.0606.0603H7.26.IK.HA 6 5.67 75 12 35 6 W0606060350
7.0 HSC-DR.UN.0606.0700H7.49.IK.HA 8 6.58 100 16 60 6 W0606070050
7.97 HSC-DR.UN.0606.0797H7.48.IK.HA 8 7.49 100 16 60 6 W0606079750
7.98 HSC-DR.UN.0606.0798H7.48.IK.HA 8 7.5 100 16 60 6 W0606079850
7.99 HSC-DR.UN.0606.0799H7.48.IK.HA 8 7.51 100 16 60 6 W0606079950
8.0 HSC-DR.UN.0606.0800H7.48.IK.HA 8 7.52 100 16 60 6 W0606080050
8.01 HSC-DR.UN.0606.0801H7.48.IK.HA 8 7.53 100 16 60 6 W0606080150
8.02 HSC-DR.UN.0606.0802H7.48.IK.HA 8 7.54 100 16 60 6 W0606080250
8.03 HSC-DR.UN.0606.0803H7.48.IK.HA 8 7.55 100 16 60 6 W0606080350
9.97 HSC-DR.UN.0606.0997H7.61.IK.HA 10 9.37 120 20 76 6 W0606099750
9.98 HSC-DR.UN.0606.0998H7.61.IK.HA 10 9.38 120 20 76 6 W0606099850
9.99 HSC-DR.UN.0606.0999H7.61.IK.HA 10 9.39 120 20 76 6 W0606099950
10.0 HSC-DR.UN.0606.1000H7.61.IK.HA 10 9.4 120 20 76 6 W0606100050
10.01 HSC-DR.UN.0606.1001H7.61.IK.HA 10 9.41 120 20 76 6 W0606100150
10.02 HSC-DR.UN.0606.1002H7.61.IK.HA 10 9.42 120 20 76 6 W0606100250
10.03 HSC-DR.UN.0606.1003H7.61.IK.HA 10 9.43 120 20 76 6 W0606100350
11.97 HSC-DR.UN.0606.1197H7.53.IK.HA 12 11.25 120 20 71 6 W0606119750
11.98 HSC-DR.UN.0606.1198H7.53.IK.HA 12 11.26 120 20 71 6 W0606119850
11.99 HSC-DR.UN.0606.1199H7.53.IK.HA 12 11.27 120 20 71 6 W0606119950
12.0 HSC-DR.UN.0606.1200H7.53.IK.HA 12 11.28 120 20 71 6 W0606120050
12.01 HSC-DR.UN.0606.1201H7.53.IK.HA 12 11.29 120 20 71 6 W0606120150
12.02 HSC-DR.UN.0606.1202H7.53.IK.HA 12 11.3 120 20 71 6 W0606120250
12.03 HSC-DR.UN.0606.1203H7.53.IK.HA 12 11.31 120 20 71 6 W0606120350 Solid carbide tools / Reaming
14.0 HSC-DR.UN.0606.1400H7.60.IK.HA 14 13.16 130 22 81 6 W0606140050
16.0 HSC-DR.UN.0606.1600H7.74.IK.HA 16 15.04 150 25 98 6 W0606160050
18.0 HSC-DR.UN.0606.1800H7.71.IK.HA 18 16.92 150 25 98 6 W0606180050
20.0 HSC-DR.UN.0606.2000H7.66.IK.HA 20 18.8 150 25 96 6 W0606200050
