Page 207 - Ceratizit Catalog

HSK-T DDMN...
A186
MaxiLock D

d
48° A

D min
48°
45° 27° l 1

45°

f
Picture shows right-hand version

L N R
d A Type, l 1 D min f
[mm] description [mm] [mm] [mm]

63 HSK-T63-DDMNL-15 L 130 110 0 DN.. 1506.. E01

100 HSK-T100-DDMNL-15 L 160 120 0 DN.. 1506.. E01

Turning / Tools ext.
E01 11224545 11224494 11211562 11224503

A303 A67-A69 A79
