HSK-T SVMC...
   A199
             MaxiLock S








            50°                                                                                                 d A


                                                                                          D min
                                                                                              50°
                                                                    47°                                   l  1
                                                                                      47°
                                                                                             f
           Picture shows left-hand version

                                            L  N  R
              d A   Type,                               l 1           D min           f
              [mm]  description                       [mm]            [mm]           [mm]

              63    HSK-T63-SVMCL-16         L            130            110            0         VC.. 1604..  E01
