MaxiMill HEC system
B102
AHEC-11 adjustable (A)
88° Ø d
H6
Ø d A
h
a
88°
Ø d 1
d 1 Type, h d d A a z n max
-1
[mm] description [mm] [mm] [mm] [mm] [min ] [Nm]
50 AHEC.50.R.06A03-11 40 48 22 4 6 12700 3.2 LN.X 1106 E01
63 AHEC.63.R.08A04-11 40 48 22 4 8 10100 3.2 LN.X 1106 E01
80 AHEC.80.R.10A05-11 50 58 27 4 10 8000 3.2 LN.X 1106 E02
100 AHEC.100.R.12A06-11 50 78 32 4 12 6400 3.2 LN.X 1106 E03
125 AHEC.125.R.16A08-11 63 88 40 4 16 5100 3.2 LN.X 1106 E04
160 AHEC.160.R.20A10-11 63 100 40 4 20 4000 3.2 LN.X 1106 E05
E01 24647 11167992 11645528 11149570 8095018900 8095010500
E02 24647 11167992 11645529 11149570 8095018900 8095010500
E03 24647 11167992 11645530 11149570 8095018900 8095010500
E04 24647 11167992 11645531 11149570 8095018900 8095010500
Milling / Face milling
E05 24647 11167992 11149570 8095018900 8095010500
