MaxiMill HDM system
B107
AHDM
75°
Ø d
Ø d
A
75° h
a
Ø d
1
Ø d
2
d 1 Type, d 2 h d d A a z
[mm] description [mm] [mm] [mm] [mm] [mm] [Nm]
160 AHDM.160.R.08-75-22 160.2 63 110 40 20 8 5 LNUC 22.. E01
200 AHDM.200.R.10-75-22 200.2 63 131 60 20 10 5 LNUC 22.. E01
250 AHDM.250.R.12-75-22 250.2 63 174 60 20 12 5 LNUC 22.. E01
315 AHDM.315.R.14-75-22 315.2 80 226 60 20 14 5 LNUC 22.. E01
Milling / Face milling E01 11423964 11417922 8095010500
