P. 43
Grade description
A22
H10T HW-N15 | HW-K15 ● ●
Specification:
Composition: Co 6.0%; WC balance | Grain size: 1 µm | Hardness: HV 1630
30
Recommended application:
The uncoated carbide grade for the machining of aluminium and other non-ferrous metals.
H216T
HW-N15 | HW-K15 ● ●
Specification:
Composition: Co 6.0%; WC balance | Grain size: 1 µm | Hardness: HV 1630
30
Recommended application:
The uncoated carbide grade for the machining of aluminium and other non-ferrous metals.
CTP5110 HC-S15 | HC-M15 ● ○
Specification:
Composition: Co 6.0%; WC balance | Grain size: 0.8 µm | Hardness: HV 1820 | Coating
30
specification: PVD TiAlN
Recommended application:
The alternative when machining heat-resistant materials.
CTP5115 HC-S15 | HC-M15 ● ○
Specification:
Composition: Co 6.0%; WC balance | Grain size: 0.8 µm | Hardness: HV 1820 | Coating
30
specification: PVD TiAlN-TiN
Recommended application:
Turning / Introduction
The first choice for the machining of heat-resistant materials.
