Page 654 - Ceratizit Catalog

The easy way to success
C49
Recommended application

Circlip grooves L/N/R

○ Insert for circlip grooves according to DIN 471-472
○ For internal and external machining

Application

Feed rate for grooving operations

5,25

4,25
Cutting width s [mm] 1,95 - 2,25
2,75 - 3,25

0,6 - 1,7

0,05 0,10 0,15 0,20 0,25 0,30 0,35 0,40 0,45
Feed rate f [mm/rev]

Parting and grooving / Introduction
