Grooving and turning – external
C79
Monoblock tools – GX

L R
h s min s max T max
Type,
[mm] [mm] [mm] [mm] description
10 2.00 3.75 7 R E10R00-1010M-GX09 GX09.. C151
C188 10 2.00 3.75 7 L E10L00-1010M-GX09 GX09.. C151

L R
h s min s max T max
Type,
[mm] [mm] [mm] [mm] description
12 2.00 2.75 12 R E12R0012-1212K-GX16-1 GX16-1.. C151
12 2.76 3.75 12 R E12R0012-1212K-GX16-2 GX16-2.. C151
16 2.00 2.75 12 R E16R0012-1616K-GX16-1 GX16-1.. C151
16 2.76 3.75 12 R E16R0012-1616K-GX16-2 GX16-2.. C151
16 3.76 5.00 12 R E16R0012-1616K-GX16-3 GX16-3.. C151
20 2.00 2.75 12 R E20R0012-2020K-GX16-1 GX16-1.. C151
20 2.76 3.75 12 R E20R0012-2020K-GX16-2 GX16-2.. C151
20 3.76 5.00 12 R E20R0012-2020K-GX16-3 GX16-3.. C151
25 2.76 3.75 12 R E25R0012-2525M-GX16-2 GX16-2.. C151
C189 25 3.76 5.00 12 R E25R0012-2525M-GX16-3 GX16-3.. C151
12
2.75
C151
2.00
L
GX16-1..
E12L0012-1212K-GX16-1
12
12 2.76 3.75 12 L E12L0012-1212K-GX16-2 GX16-2.. C151
16 2.00 2.75 12 L E16L0012-1616K-GX16-1 GX16-1.. C151
16 2.76 3.75 12 L E16L0012-1616K-GX16-2 GX16-2.. C151
16 3.76 5.00 12 L E16L0012-1616K-GX16-3 GX16-3.. C151
20 2.00 2.75 12 L E20L0012-2020K-GX16-1 GX16-1.. C151
20 2.76 3.75 12 L E20L0012-2020K-GX16-2 GX16-2.. C151
20 3.76 5.00 12 L E20L0012-2020K-GX16-3 GX16-3.. C151
25 2.76 3.75 12 L E25L0012-2525M-GX16-2 GX16-2.. C151
25 3.76 5.00 12 L E25L0012-2525M-GX16-3 GX16-3.. C151
L R
h s min s max T max
Type,
[mm] [mm] [mm] [mm] description
16 2.00 2.75 21 R E16R0021-1616K-GX24-1 GX24-1.. C151
16 2.76 3.75 21 R E16R0021-1616K-GX24-2 GX24-2.. C151
20 2.00 2.75 21 R E20R0021-2020K-GX24-1 GX24-1.. C151
20 2.76 3.75 21 R E20R0021-2020K-GX24-2 GX24-2.. C151
20 3.76 5.00 21 R E20R0021-2020K-GX24-3 GX24-3.. C151
25 2.76 3.75 21 R E25R0021-2525M-GX24-2 GX24-2.. C151
25 3.76 5.00 21 R E25R0021-2525M-GX24-3 GX24-3.. C151
25 5.01 6.50 21 R E25R0021-2525M-GX24-4 GX24-4.. C151
32 2.76 3.75 21 R E32R0021-3225P-GX24-2 GX24-2.. C151
32 3.76 5.00 21 R E32R0021-3225P-GX24-3 GX24-3.. C151
C190 32 5.01 6.50 21 R E32R0021-3225P-GX24-4 GX24-4.. C151
2.00
2.75
21
C151
E16L0021-1616K-GX24-1
L
16
GX24-1..
16 2.76 3.75 21 L L L L L E16L0021-1616K-GX24-2 GX24-2.. C151
C151
GX24-1..
E20L0021-2020K-GX24-1
21
2.75
2.00
20
Parting and grooving / Application 25 3.76 5.00 21 L L L L L E25L0021-2525M-GX24-3 GX24-3.. C151
E20L0021-2020K-GX24-2
3.75
2.76
C151
GX24-2..
21
20
C151
GX24-3..
20
3.76
5.00
E20L0021-2020K-GX24-3
21
25
E25L0021-2525M-GX24-2
3.75
21
C151
2.76
GX24-2..
E25L0021-2525M-GX24-4
21
6.50
C151
5.01
25
GX24-4..
GX24-2..
3.75
C151
2.76
21
E32L0021-3225P-GX24-2
32
GX24-3..
C151
3.76
21
E32L0021-3225P-GX24-3
5.00
32
C151
32
5.01
GX24-4..
E32L0021-3225P-GX24-4
6.50
21
