Grooving and turning – internal
C81
Modular system – internal, assembly size 16
T max
Ø D s
Matching products see right-hand side.
L R L R
d A D min s min s max T max
Type, Type,
[mm] description [mm] [mm] [mm] [mm] description
20 R MSS-I16R90-1.5D-N 20 2.00 2.75 4 R MSS-I16R04-GX09-1 GX09-1.. C151
C207 C210 20 2.76 3.75 4 R MSS-I16R04-GX09-2 GX09-2.. C151
20 R MSS-I16R90-2.5D-N
C208
L R L R
d A D min s min s max T max
Type, Type,
[mm] description [mm] [mm] [mm] [mm] description
20 L MSS-I16L90-1.5D-N 20 2.00 2.75 4 L MSS-I16L04-GX09-1 GX09-1.. C151
C207 C210 20 2.76 3.75 4 L MSS-I16L04-GX09-2 GX09-2.. C151
20 L MSS-I16L90-2.5D-N
C208
